Connect upstream cable from source to hub
1
Remove screw (fig. P) from cable retaining clip
2
Remove plastic insert (fig. Q) from retaining clip and insert USB-C upstream cable
3
Snap plastic insert back into retaining clip and secure with screw
4
When attaching USB - A-to-C adapter, make sure to properly align connector head with adapter upon insertion
①
P
5
When attaching USB - A-to-C adapter, make sure to properly align connector head with adapter upon insertion
④
10
②
Q
③
⑤
