Note: If you are switching on the system for the first time, all the saved positions are set to
the lowest desktop height (minimum desktop position).
1. Adjust the desktop to the position you want to save.
The display will show the desktop height (e.g. 73 cm).
2. Press the S-Key.
The display will read S –.
3. Press the required memory position key (e.g. 2)
The display will read S 2.
4. The set desktop position will now be saved to the
selected memory position key.
You will hear an audible double click and after about 2 seconds
the saved desktop position will be displayed.

3.6.2 Adjusting the desktop to a saved position

You can use this function to adjust the desktop to a saved height.
1. Press the required memory position key (e.g. 2) and
hold it down.
The desktop will move until it reaches the saved position.
If you release the key before the saved position is reached, the desktop will stop
and the saved desktop position will not be reached.
2. The desktop has reached the saved position.
Now release the memory position key.
The display will read the current (saved) desktop position.
3.6.3 Resetting the control unit to the factory settings (S0-menu)
With this function the control unit can be reset to the factory settings.
1.
2.
3.
Danger: If lifting columns are replaced in a desk system, a prior reset of the control unit to the
factory settings via manual reset is mandatory.
Press the memory position 1, 2 and desktop up keys at the same time.
Keep the key combination pressed for about 3 Seconds. Then release the
keys.
The display will read S and a number, e.g. S 5.
Press the desktop up key until the display reads S 0.
The display will show S 0.
Press the S key.
The control unit is reset to the factory settings. The control unit now has the
same settings as at the commissioning stage.
073
S -
S 2
073
073
