Kobra FlexPack is designed exclusively to
transform used cardboard boxes into padded
filling material and padding mats either as
a packing/cushioning material or as a filling
material. Reading this manual will enable you
to get the best perfomance from your KOBRA
FLEXPACK.
INTRODUCTION
The machine is delivered on a wooden pallet to
ensure it is not damaged during transportation.
You will need:
- Hex key 13 mm
- Pliers or scissors
- Hammer
PACKAGING
Use the pliers or scissors to cut the straps (1)
and remove the cardboard (2) from the pallet
Your Kobra FlexPack is equipped with a high tech TOUCH SCREEN control panel. Simply touch the
control on the panel in order to activate the functions of the machine.
14
PACKAGING AND INSTALLATION

CONTROL PANEL

Touch the FORWARD (1) [Pic.B] button and the
FORWARD
machine starts the cutting knives.
Touch the STOP (2) [Pic.B] button and the machine
STOP
stops immediately.
Touch the REVERSE (3) [Pic.B] button and the device
REVERSE
puts the cutting knives into reverse mode.
Your machine is equipped with a LOAD METER (4)
[Pic.B] that enables you to check the processing
capacity of Kobra FlexPack. For a constant and efficient
processing capacity it is recommended to keep the
LOAD METER with only the first 4 blue LED on to avoid
unintended jams.
In case of emergency, press STOP (8) [Pic.C] button to
stop all functions of the machine.
Pic. A, Page 13
(3). Shredder is attached to the pallet by means
of the transport bars (5).
Remove all the packing material protecting the
machine.
Remove the transport bars (5) using the hex key
13 mm as shown in figure.
Fix the slides (6) to the pallet with the nails (7)
supplied. Now you can start to push your Kobra
FlexPack off the pallet. Warning! Kobra FlexPack
should be taken off the pallet by at least 2
people.
INSTALLATION
Use an accessible outlet near the device.
Connect the power cable of Kobra FlexPack to
the outlet. Your Kobra FlexPack is now ready to
be turned on.
Pic. B, Page 15
