Comply with the official instructions provided by the competent authorities in merit when installing the disposal duct. In
addition, exhaust air should not be discharged into a wall cavity, unless the cavity is designed for that purpose.
The room must be well aerated in case a hood and some other heat equipment fed with an energy other than electricity
(gas, oil, coal heaters, etc) operate at the same time.
In fact the intake hood, disposing of air, could create a vacuum in the room. The vacuum should not exceed 0,04mbar.
This prevents the gas exhausted by the heat source from being intaken again. It is therefore advisable to ensure the room
contains air taps able to ensure a steady flow of fresh air.
Check the data label inside the appliance; if the symbol ( ) is printed, read the following: this appliance has such
technical particulars that it belongs to class II insulation, therefore it must not be earthed.
Check the data label inside the appliance; if the symbol ( ) is NOT printed, read the following: ATTENTION: This
appliance must be earthed. When making the electrical connections, check that the current socket has a ground
connection.
When making the electrical connections, check that the voltage values correspond to those indicated on the data plate
inside the appliance itself. In case your appliance is not furnished with a non separating flexible cable and has no plug,
or has not got any other device ensuring omnipolar disconnection from the electricity main, with a contact opening
distance of at least 3 mm, such separating device ensuring disconnection from the main must be included in the fixed
installation. If your unit features a power lead and plug, position this so the plug is accessible.
Always switch off the electricity supply before carrying out any cleaning or servicing operations on the appliance.
USE
Avoid using materials which could cause spurts of flame (flambées) near the appliance.
When frying, take particular care to prevent oil and grease from catching fire. Already used oil is especially dangerous
in this respect. Do not use uncovered electric grates.
To avoid possible risks of fire always comply with the indicated instructions when cleaning anti-grease filters and when
removing grease deposits from the appliance.
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not
play with the appliance.
Caution: accessible parts may become hot when used with cooking appliances.
This kitchen hood is intended for installation in domestic kitchens above cooktops, cooking devices and similar kitchen
equipment.
MAINTENANCE
Thorough servicing guarantees correct and long-lasting operation.
Any fat deposits should be removed from the appliance periodically depending on amount of use (at least every 2
months). Avoid using abrasive or corrosive products. To clean painted appliances on the outside, use a cloth dipped in
lukewarm water and neutral detergent. To clean steel, copper or brass appliances on the outside, it is always best to use
specific products, following the instructions on the products themselves. To clean the inside of the appliance, use a cloth
(or brush) dipped in denatured ethyl alcohol.
DESCRIPTION
The unit can be found in filtering hoods or ducting hoods. In the Filtering version the air and the kitchen fumes
that are conveyed by the apparatus are depurated by the charcoal filter and put back into the room (Fig. 1).
ATTENTION: When using the filtering version, a charcoal filter and an air baffle (Fig.1A) must be used, which placed
at the top of the structure, allows the air to recycle back into the room. In the Ducting version, cooking vapours and
odours are conveyed straight outside by a disposal duct which passes through the ceiling (Fig.2).
INSTALLATION
ATTENTION: 3 persons are required for proper installation; the unit should be installed by a qualified
operator. Also follow carefully each step of the assembly instructions, and once installation has been
completed, make sure that the hood is firmly secured in place.
Before proceeding with assembly, slide out the upper tube to make manoeuvres with the equipment easier and
remove the grease filter. Push the handle towards the outside and pull the filter down (Fig. 3).
Remove the cross member on the control side by removing the 2 screws (Fig.4A), disconnect the control connector,
then remove the rear cross member by removing the 2 screws (Fig.4B), remove the two lamp covers by removing the
4 screws (Fig.4C), disconnect the connector and run the cable through the hole, remove the 4 screws (D) and finally
remove the lower flue.
Essential requirements for assembly: – Prepare electricity supply inside the the telescopic flue – If your appliance
is to be installed as a Ducting version, prepare the air evacuation hole. When installing ducting hoods, to achieve the
best possible conditions use an air exhaust pipe that : is as short as possible, has a minimum of curves (maximum
angle: 90°), is made of a material that complies with the standards (which vary from nation to nation) and iv) is smooth
on the inside. It is also advisable to avoid any drastic changes in pipe section (diameter: 150 mm).
