APPLICATION OF HAND BRAKES
1. Pull the brake towards the handgrips.
2. Do one of the following:
A. STILL - hold the brake handle up:
B. MOVING - Release the brake handle
Fig. 5 (unlocked state) Fig. 6 (locked state)
HANDBRAKE LOCKING
1. Push down on the bottom of the brake handle in compliance
with the drawing until you hear a click (Fig. 6)
2. For more information, see UNLOCKING
HANDBRAKE in this manual.
UNLOCKING THE HAND BRAKES
Pull the brake handles upwards until they are released as shown in fig. 5.
2. Release the brake handle.
3. Make sure the brake cable is running along the sideline and the unused part is coiled in front of the walker.
TECHNICAL PARAMETERS
Overall width: 64 cm
Overall length: 82 cm
Overall height: 92.5 cm
Seat width: 45 cm
Seat depth: 23.5 cm
Seat height: 55 cm
Rear wheels: 8-inch PVC wheels
Front wheels: 9-inch PVC wheels
Weight：8.1kg
Package size: 86*26*37cm
Adjustable handle height: 79-91cm
Maximum payload: 136kg
THIS SIGN MEANS A MAXIMUM WEIGHT OF THE USER!
CLEANING
Rollator can be cleaned with a damp cloth or sponge anwarm soapy water. Domestic anti-bacterial surface cleanersmay be used if required. Care should be
taken not to leaveany cleaning residues on the handgrips or seat (where fifi tted) which may leave them slippery when used. Do not use scouring pads as this
may damage surface coatings.
MAINTENANCE
1. Please ensure that all attachments are always secured.
2. Check the bolt securing the seat to the side elements. Tighten as needed.
3. Replace any damaged or damaged parts immediately.
WHEEL MAINTENANCE
1. Wheels should be cleaned with warm water and a mild detergent. Pat dry with a dry cloth.
2. Periodically lubricate with 3-in-1 grease if the wheels begin to squeak.
STORAGE
The product should be stored in a dry and cool room. Do not expose to direct sunlight.
TARGET PATIENT GROUP
The healthcare professional shall indicate the use of the device to adults and children on his/her own responsibility, taking into account the available
variants/sizes/necessary functions/sizes and indications, bearing in mind the information provided by the manufacturer.
METHOD OF DISPOSAL OF THE PRODUCT AFTER REMOVING FROM SERVICE
After the device is withdrawn from use, the medical device can be disposed of as normal municipal waste, except for
electrical products - proceed in the manner appropriate for the disposal of electrical and electronic equipment .
