Product description

System description

The sanitary module is equipped with user detection, an odour extraction unit and an
orientation light.
Soft-touch buttons are integrated into the cistern lid and can be used to actuate a large or
small flush.
The integrated odour extraction unit neutralises unpleasant odours in the WC ceramic
appliance.
Technical data and conformity

Technical data

Nominal voltage
Mains frequency
Operating voltage
Power consumption
Power consumption in standby mode
Mains connection
Flow pressure range
Flush volume factory setting
Odour extraction unit run-on time factory
setting
Wireless technology radar
Frequency range
Maximum output power
Bluetooth® wireless technology
Frequency range
Maximum output power
Communication protocol for light control
Energy efficiency class light source
1)
The Bluetooth® brand and its logos are the property of Bluetooth SIG, Inc. and are used under licence
by Geberit.
9007209651644683 © 11-2022
971.480.00.0(00)
100–240 V AC
50–60 Hz
12 V DC
15 W
< 0.5 W
Direct connection via system plug with
flexible three-wire sheathed cable
0.1–10 bar
10–1,000 kPa
6 and 3 l
2 min
Short-range radar sensor
5.75–5.85 GHz
≤ 7 dBm EIRP
1)
Bluetooth Low Energy
2400–2483.5 MHz
4 dBm
DALI-2
D
