Z30 SMART • Z50 SMART • Z80 SMART • Z120 SMART • Z150 SMART • Z200 SMART
When receiving the product, please,
check the packaging for the following
accessories (1 pc of each one):
• Instructions for installation and use
• Guarantee document
• Safety valve (Parameters:
0.65 ±0.05 MPa opening pressure,
operational up to 100 °C, equipped
with drinking
manually operated blow­off device,
valve with Rp1/2 connection on the
outlet side.)
This closed system electrically heated hot water container can supply hot waterto
one or more water withdrawing locations within households or institutions .
The hot water obtained is suitable for sanitary and consumption purposes, if it
isof drinking water quality, i.e. complies with limit values laid down in Government
Decree No. 201/2001 (X.25.). Having regard to the fact that hot water has a higher
capacity to dissolve metals, it is recommended to use cold water for cooking and
drinking, and consume it after heating, when hot water is needed.
Upon reaching the preset temperature (8.3), the heating is automatically
turned off by the temperature regulator. The polyurethane heat insulation
surroundingthe inner tank prevents the fast cooling of the water, thus ensuring
the availabilityof hot water from the container over a long time. Due to the de-
sign of the container, hot water is discharged unmixed. The corrosion protection
of the inner tank is ensured by a special enamelling andactive anodes. The
enamelled design ensures long service life, even in the case ofaggressive (soft)
water .

4. MOUNTING AND INSTALLATION OF THE TANK

The mounting (4) of the hot water tank, as well as its connection tothe
water (5) and electrical network (6) and commissioning mustbe performed
by a qualified professional according to our instructions and observing
22 2

2. ACCESSORIES

PN10,
water compliant,

3. PRINCIPLE OF OPERATION

the standards IEC 60364 / MSZ HD 60364.
