Horizon Hobby Axial SCX10 PRO Bedienungsanleitung Seite 25

G4
M3 x 12mm BH
CMS
AXIC0116 x1
EN Drag Link CMS (57.4mm)
DE Lenkzwischenstange CMS (57,4 mm)
FR CMS barre de direction (57,4 mm)
IT Tirante CMS (57,4 mm)
AXIC0286
G4
M3 x 10mm BH
AMS
AXIC0115 x1
AXIC0012
AXIC0116
EN AMS (Axle Mounted Servo) Option
DE AMS (Axle Mounted Servo) Achsenmontiertes Servo
FR Option AMS (Servo monté sur essieu)
IT AMS opzione servo su assale
M3 x 16mm BH M3 x 25mm BH
AXI235110 x2 AXIC0012 x1
M3 x 12mm BH M3 x 16mm BH
AXIC0116 x1 AXI235110 x3
AXIC0115
AXI231055
AXI231056
25T
THREAD
LOCK
M4 x 12mm
AXIC0286 x1
AXIC0012
AXIC0116
AXI235110
M3 x 25mm BH M4 x 12mm
AXIC0012 x1 AXIC0286 x1
EN 30m77mm (1.21) Drag Link AMS
DE 0 m 77 mm (1,21) Lenkzwischenstange AMS
FR AMS barre de direction 30 m 77 mm (1.21)
IT Tirante AMS (77 mm)
23T
EN 1 drop
DE 1 Tropfen
FR 1 goutte
IT 1 goccia
AXI235110
AXIC0286
25
AXI235110
AXI235110
