5. Package List

6. Assembly Guide

Step 1 Install The Front Wheel
A) Take out the bike and make it stand up.
B) Loose the nut to remove the temporary protected bar.
C) Insert the wheel between the fork blades so that the axle can seat firmly at the fork dropouts (the
slots at the tip of the fork blades).
D) Put the gaskets on it and tighten the nuts.
Note: if the lever cannot be pushed all the way to a position parallel to the fork blade, return the lever to the
OPEN position. Then turn the tension adjusting nut counterclockwise and make a one-quarter turn, and try
tightening the lever again.
Step 2 Adjust The Stem
A) Undo the stem bolts slightly till you can turn the stem.
B) Align the stem with the front wheel.
C) Tighten up the stem bolts.
04
Eleglide E-bike x 1
Pedal x 2
Spoke Reflector x 2
User Manual x 1 Charger x 1
Tool Kit x 1 Key x 2
Rear Reflector x 1
