BR976A04a
© 2015 OJ Electronics A/S
Fig. 1 - Disassemble temperature sensor
BR976A011a
© 2015 OJ Electronics A/S
Fig. 3 - Disassembly connection box
1 - 2
3 - 4 - 5
Din1
Din2
Din3
SD CARD
®
www.oj.dk
Aou1 Aou2 Aou3
20 - 21 - 22 - 23
24 - 25
BR976A006a
Fig. 6 - Connection diagram
© 2015 OJ Electronics A/S
4
Fig. 2 - Dimensions temperature sensor
BR976A010a
© 2015 OJ Electronics A/S
Fig. 4 - Dimensions connection box
BR976A002a
© 2015 OJ Electronics A/S
6 - 7 - 8
9 - 10 - 11
12 - 13 - 14 - 15
VAV
VAV
FIRE
CO 2
CO
2
Din4 Din5
Din6
Ain1 Ain2
TCP/IP
OJ Air2 Master
RS485
Dou1
Dou2
Dou3
Dou4
1
2
A
26 - 27
28 - 29
30 - 31
The trademark is registered and belongs to OJ Electronics A/S · © 2019 OJ Electronics A/S
56 x 56
23,6
51,5 mm
20,5 mm
16 - 17 - 18 - 19
+24V
Aou
Tin1
Tin2
MODBUS
RS485
RS485
RS485
A
B
C
Dou5
Dou6
Dou7
1
2
B
32 - 33
34 - 35
36 - 37
V-
V+
B
A
BR976A008a
Fig. 5 - Rotary selector
© 2015 OJ Electronics A/S
Position
Modbus adr.
0
0x10 (hex) / 16 (dec.)
1
0x11 (hex) / 17 (dec.)
2
0x12 (hex) / 18 (dec.)
3
0x13 (hex) / 19 (dec.)
4
0x14 (hex) / 20 (dec.)
5
0x15 (hex) / 21 (dec.)
6
0x16 (hex) / 22 (dec.)
7
0x17 (hex) / 23 (dec.)
8
0x18 (hex) / 24 (dec.)
9
0x19 (hex) / 25 (dec.)
A
0x1A (hex) / 26 (dec.)
B
0x1B (hex) / 27 (dec.)
C
0x1C (hex) / 28 (dec.)
D
0x1D (hex) / 29 (dec.)
E
0x1E (hex) / 30 (dec.)
F
0x1F (hex) / 31 (dec.)
Tabel 1. Modbus adresses
^
^
OJ ELECTRONICS A/S
Stenager 13B
DK-6400 Sønderborg
Tel. +45 7312 1314
Fax +45 7312 1313
oj@ojelectronics.com
www.ojelectronics.com
