EN
SETTING UP WORKPIECE
Setting up with tailstock (5) and
4-prong drive (1)
1.
Mark out the centre of the workpiece
ends with diagonal lines over the ends.
The centre is the point where the lines
cross. Make a centre hole where the
prong drive and tailstock are to be put.
This ensures that the workpiece is
held more firmly in place.
2.
Saw a 2 mm deep cut along the diagonal
lines to give the 4-prong drive (1) a better
grip.
3.
Release the prong drive (1) from the
product and put it against the centre mark
on the workpiece. Carefully tap the prong
drive (1) with a mallet (sold separately)
so that it is pressed into the workpiece.
Protect the back end of the prong drive (1)
with a piece of wood.
4.
Remove the prong drive (1) from the
workpiece.
5.
Replace the prong drive (1) on the
product.
Fitting and removing 4-prong drive
1.
Put the workpiece on the 4-prong drive
(1). Align the 4-prong drive (1) to the mark
in the workpiece.
2.
Release the tailstock locking lever (8).
3.
Bring the tailstock to the prong drive
(1) so that the prongs almost touch the
workpiece.
4.
Lock the tailstock in place by pressing
down the locking lever (8).
5.
Fine-adjust the tailstock with the crank
(6).
6.
Lock the crank in place with the lock nut
(4).
36
SETTING UP WITH FACE PLATE ( 13 )
1.
Hold the drive axle (19) with a spanner
(16).
2.
Remove the face plate (13) from the drive
axle (19).
3.
Secure the workpiece on the face plate
(13) with wood screws (sold separately).
WARNING!
Risk of personal injury. Make sure to place
the screws so that they cannot come into
contact with the lathe tool during the
turning.
4.
Hold the drive axle (19) with a spanner
(16).
5.
Screw the face plate (13) with the
workpiece on the drive axle (19).
ADJUSTING THE TOOL REST
WARNING!
Risk of personal injury. Always check before
use that the tool rest is correctly installed and
cannot come loose.
Locking/releasing tool rest
1.
Lock the tool rest (2) in place by pressing
down the locking lever (9).
2.
Release the tool rest (2) by bringing up
the locking lever (9). The tool rest can
now be moved.
HEIGHT ADJUSTMENT OF TOOL
REST
1.
Undo the screw (2.1) on the base (2.2) of
the tool rest.
2.
Adjust to the required height.
3.
Lock the tool rest (2) in place by
tightening the (2.1).
