② Input Meter Displays the strength of the input signal and whether that signal is mono or stereo. The loudest peaks should
reach within the target range (indicated by the shaded region between -12 and -3 dB).
③ Microphone Gain Adjust the mic gain slider to set the volume of the sound source.
④ Custom Presets Tap the caret to quickly access your saved presets. Or tap the Save button to save current settings. See
Custom Presets for more information.
⑤ Preset Modes Set stereo width, equalization, and compression for specific applications. See "Preset Modes" for more infor-
mation.
⑥ Polar Pattern Selection Swipe to choose your pick-up pattern. Use the handles to adjust the width of the stereo image.
Tip: Consider the location of the microphone and the size of the sound source when adjusting the width. For example, a large orchestra or ensemble recording
benefits from a wide stereo image, which increases separation between instruments. Speech benefits from a narrow width, which improves clarity and rejects
ambient (room) sound.
⑦ Stereo Width Handles Use the dots to quickly set stereo width.
⑧ Advanced Features Fine tune your audio recording with limiter and compressor controls, high pass filter, left-right swap,
and equalization settings.

Preset Modes

Five selectable modes optimize settings for gain, stereo width, equalization, and compression. Set the microphone level and try
the modes to find which sounds best. Preset modes can affect the strength of the input signal, so adjust the microphone level
as needed after changing presets.
Mode Application
speech
Speech
solo or group vocal per-
formances
Singing
any
Flat
acoustic instruments and
quiet music
Acoustic
live performance and lou-
der sources
Loud

Direct Monitoring Blend

There are two ways to access the Direct Monitoring slider when you want to adjust your monitor source. Tap the input meter to
view the mic gain and monitoring blend sliders. Or you can view the slider by tapping the headphone icon in the device settings
tab.
Characteristics
Narrow stereo width to reject background noise, equalization that emphasizes cla-
rity and fullness, and gentle compression.
Medium stereo width with subtle equalization to add richness and clarity for a na-
tural sound.
An unprocessed signal (no equalization or compression settings used). Adds flexi-
bility when processing the audio after recording.
Medium stereo width with transparent compression to smooth out volume spikes
and bring out quiet passages. The equalizer setting emphasizes detail and an
overall natural sound.
Wide stereo to increase separation between sources. Equalization further impro-
ves definition by reducing frequencies that can make the instrumentation sound
crowded.
Shure Incorporated
11/19
