1.3.1. Adjusting the Saddle height

The correct saddle height is reached when: You are sitting on the
saddle and your leg is almost straight when putting the ball of your
foot on the pedal. The cranks arms are thereby aligned vertically.
To check the saddle height, sit on the bike and go for a test ride or
lean against a wall to feel if the height is comfortable.
To change the saddle height, proceed as follows:
Step 1. Loosen the screw of the seat post clamp
with the Allen key provided in the Modmo
Toolbox until the seat post can move freely
5mm
6
YO UR B I KE
Step 2. Adjust to the desired height (not
exceeding the minimum insertion height)
Important Information:
The seat post clamp is tightened enough when the seat post
cannot be turned or when it no longer slides down into the seat
tube under your weight.
Attention:
Do not clamp the seat post above the minimum insertion
height or you will be at serious risk of injury. The seat post is a
part of the electrical system. Do not remove the seat post from
the frame. It will damage the wiring system and could result in
an electrical fault. In case of damage, please contact Modmo
Customer Service or a Modmo Service Centre in your area.
Step 3. Retighten the screw to a torque of
5-12 Nm. Do not over-tighten the bolt as it
can cause it to break
