2.6. Gates Carbon Drive System:
Gates User Manual
When delivered, the belt is optimally tensioned but may need
to be re-tensioned after prolonged use or removal of the rear
wheel. Correctly mounted, the belt is extremely resilient in the
pulling direction. The carbon fibers embedded in the belt are
very flexible but sensitive to the following issues:
Crimping Twisting
Zip tying Mounting the tensioned belt
with a lever, and/or by rotating the cranks
Important Information:
Please be aware that use of the Gates Carbon Drive system in ice and snow,
can lead to the teeth of the pulleys becoming clogged. This can lead to the
belt being pushed off of the pulley, or lifted up and ratcheting over it. Both of
these possibilities could reduce the safe operation of the system. For this
reason, the use of the bike in snow and ice should be avoided. The use of the
system in mud should also be avoided for the same reasons.
Please refer to Gate's Carbon Drive:
https://www.gatescarbondrive.com/~/media/files/gcd/owners-manuals/englis
h-owners-manual-gates-carbon-drive.pdf?la=en
Bending Inverting
Backwards

2.7. Brake System

Your Modmo Saigon+ E-Bike is equipped with hydraulic disc
brakes that will stop you quickly and safely when needed.
Use both brakes simultaneously for safe braking.
2.8. Kickstand's Permitted Load
The kickstand can support a maximum
load of 15kg.
Do not sit on the bike and put your
weight on the kickstand while it is down,
or put any other weight on the bike that
exceeds 15kg while the kickstand is down.
For ideal longevity, only use the kickstand
to support the bike itself.
2.9. Display Error
If there is something wrong with the electronic control
system, the display will show the error code automatically.
The following is the definition of the main error codes
Error Code Issue
Motor connection
24
issue
Abnormal
30
Communications
The display returns to normal only after the problem is fixed
and the bike will not operate before fixing the problem.
S AF E T Y IN ST R U C T ION A ND P RODU C T I NFOR MAT IO N
Common cause
Motor cable not correctly
connected after re-installing
the front wheel.
Electrical fault in wiring system.
