IMPORTANT - READ BEFORE USE
1. 'PROG' (PROGRAM) button
2. Microchip / I.D. Disc search indicator
3. Low battery indicator
4. AM/PM indicators (12Hr clock mode)
5. 'TIMER' function indicator
6. 'TIMER' mode 'Start/Finish' indicators
7. 'TIMER' button
8. '4 WAY' button
9 - 11. CAT 1 - 3 location symbols
12. '4 WAY' lock indicators
13. Alphanumeric display (normally states time)
14. 'ADVANCE' button

IMPORTANT SAFETY INSTRUCTIONS

• Read all instructions before installing or using this product.
• Register your purchase on-line at www.pet-mate.com
(see guarantee).
• Do not allow children to play with this product.
• Inspect product regularly for correct operation and
damage. Do not use if in doubt.
• This product is designed for use with pets only, as
described in these instructions.
• The locking system of this pet door is not intended as a
security device.
• This pet door is not a fire resistant door and must not be
used where there is a risk from fire spread.
• The installer of this pet door is responsible for complying
with all relevant building regulations.
• During installation of this pet door take appropriate
care. Follow safety instructions for all tools and wear
appropriate personal protective equipment.
• Dispose of all packaging material properly.
NOTE: Plastic bags could cause suffocation – keep away
from children and animals.
SAVE THESE INSTRUCTIONS
1. Introduction
Thank you for choosing the Cat Mate Elite Microchip Cat Flap
with Timer Control.
CAREFULLY READ THESE INSTRUCTIONS AND PROGRAM
/ TEST THE CAT FLAP BEFORE YOU INSTALL IT.
The Cat Mate Elite Microchip Cat Flap with Timer Control
allows entry for up to 9 cats into your property. It also allows
you to control the exit of all your pets using a timer or 4 way
lock. Furthermore, it will allow you to monitor the movement of
up to 3 individual cats - showing when your cat last entered or
left the house, and how many hours since your cat last used
the flap.
The cat flap is suitable for all popular microchips. Alternatively
it may be operated by a Cat Mate I.D. Disc (available
separately). You may wish to use an I.D. Disc for cats without a
microchip or in the event that your cat's microchip is faulty or
poorly positioned.
To ensure that your chosen settings cannot easily be tampered
with, we have made the control buttons so that they need to be
pressed firmly to operate.
If you wish to stop any task (except programming) at any stage,
the system will time out after 60 seconds.
Settings will not be saved unless you press the 'PROG' button.
2. Fitting the Batteries
2.1 R emove the battery cover by pushing the battery cover
upwards (see Fig. 2). The cover will snap off.
2.2 I nsert 4 x AA (R6) batteries as shown (Fig. 3), by sliding the
2 end batteries in first.
2.3 T he cat flap will self-check for up to 60 seconds after
which only the 'IN & OUT' arrows will be visible on the LCD
display. The flap is ready to program.
All popular batteries can be used including rechargeable
batteries, but the low battery indicator (
work correctly with alkaline batteries. Good quality alkaline
batteries should last approximately 12 months (depending
on number of cats and usage). You MUST NOT use lithium
batteries.
3. Programming
The next step is to program the microchip (or I.D. Disc)
belonging to each cat.
NOTE: The programming sequence is time sensitive and
the LCD will revert to the normal display if each step is not
completed within approximately 15 minutes.
In order for the flap to recognise your cat(s) microchip you need
to do the following:
3.1 P ress and hold the 'PROG' button for 5 seconds (
1) until the search indicator (
3.2 ' CAT 1' and the number '1' will flash - there will be lines
moving around the first 'TWO ZEROS'.
3.3 T o program your cat's microchip, encourage your cat to
slowly pass through the tunnel by holding the flap open
as shown in Fig. 4. Alternatively, to program your cat's I.D.
Disc, place the front of the I.D. Disc in the tunnel opening
(Fig. 5).
3.4 W hen programmed, the 'TWO ZEROS' will disappear and
'Pr1' will flash.
3.5 P ress the 'PROG' button to save the setting.
For additional cats, up to a maximum of 9, repeat steps 3.1
to 3.5.
4. Fitting Instructions (see Figs. 8a to 16)
IMPORTANT:
• Do not cut tunnel of cat flap.
• To check that your cat's microchip is correctly positioned
and functioning, we strongly recommend you program the
cat flap for all your cats before installation (see Section 3).
Then check the cat's microchip operates the lock when
the cat's head is pushed gently against the flap as shown
in Fig. 6.
4.1. Wooden Doors 0-50mm (0-2") Thick
4.1.1 Place exterior frame in desired position on door. We
recommend the bottom of the aperture is approximately
150mm (6") above ground level. (Fig. 8a). If you must fit
higher consider providing a step to help your cat enter.
4.1.2 Draw around the aperture (Fig. 8a), then using an electric
jigsaw cut 4mm ( 5 / ") outside of the line. (Fig. 8b).
32
Be careful to cut hole square to the door, particularly with
thicker doors. Ensure interior frame is free fitting in hole.
4.1.3 Determine thickness of door panel, (t). (Fig. 10).
4.1.4 Holding the interior frame and the exterior frame in
position, mark the 2 screw holes. (Fig. 11).
4.1.5 Remove the frames and drill screw clearance holes in
panel to 6mm ( 1 / ") diameter.
4
4.1.6 Position interior frame on inside of door and screw
exterior frame to it by using appropriate screws for panel
, Fig. 1) will only
3
, Fig.
1
, Fig. 1) appears.
