DANGER
Risk of accident due to improper installation or handling of the One Piece Cockpit!
A proper installation and handling of the One Piece Cockpit significantly contributes to the safety
of your bike. Please note:
• The One Piece Cockpit may only be used for its intended purpose.
Do not exceed the maximum system load!
• The One Piece Cockpit may only be installed by someone with sufficient expertise and
knowledge. If in doubt, please consult a qualified bicycle mechanic!
• Note the torques of the bolt connections! The 5 Nm maximum torque of the steerer clamp
must not be exceeded!
• After a fall, the One Piece Cockpit might have damages that are not externally visible.
Ask a qualified bicycle mechanic to check or – if need be – replace the One Piece Cockpit
after a fall!
• In case of cracking noises or external damages like cracks, deformations or discolorations,
the One Piece Cockpit should be replaced or serviced by a qualified bicycle mechanic.

General information / Safety

Please read these instructions carefully before your first use of the One Piece Cockpit and make
sure you understand everything. Keep this manual for future reference. If you sell or give away your
One Piece Cockpit, please also include the owner's manual.

Intended use

The One Piece Cockpit may only be used on ROSE road bikes with compatible spacers.
The One Piece Cockpit may be used on road racing bikes in their usual area of use. Do not exceed
the maximum system load of 110kg!
The One Piece Cockpit Race may only be used with wireless shifting systems.
Preparing the stem for installation
1. Check the length of the steerer tube. The clamping surface of the steerer tube must be
2 to 3 mm shorter than the upper edge of the clamping surface of the One Piece Cockpit.
2. Make sure that a steerer tube expander is mounted in the steerer tube.
3. Clean your One Piece Cockpit and steerer tube, then apply mounting paste to the clamping
surface of the stem.
Mounting the One Piece Cockpit
1. Slide the One Piece Cockpit onto the steerer tube and align it straight in the direction of travel.
2. Place the top cap (2) on the One Piece Cockpit and fully screw in the headset play adjustment
bolt (1), but do not tighten it.
3. Adjust the headset play: Tighten the headset play adjustment bolt (1) until there is no play in the
headset.
4. Tighten the bolts of the steerer clamp (3) alternately a little bit at a time until you've reached a
maximum torque of 5 Nm. That torque must not be exceeded!
5. Attach the controls to the handlebars and tighten them to a maximum torque of 6 Nm.
On the ROSE website you will find more detailed information on how to
assemble your One Piece Cockpit.
Scan this QR code to go directly to the detailed instructions.

Maintenance and care

Regular care and maintenance ensure high durability and reliability, as well as unlimited
functionality. ROSE Bikes recommends carrying out the following tasks:
• Check the bolts for proper torque regularly and tighten them to the required torque, if need be.
• Regularly clean the One Piece Cockpit with a gentle cleaning agent. Pay attention to the notes
and recommendations for use printed on the respective cleaner.
• Regularly check the One Piece Cockpit and bolts for damages like cracks, deformations and
corrosion and replace the One Piece Cockpit, if need be.
This manual is also available on rosebikes.com/manuals.
