Section 2 Specifications
2.1 Mechanical
Weight, 600 m, plastic, no pump, in air, water
Weight, 10500 m, titanium, no pump, in air, water
Weight, 5M, plastic
Weight, 5M, titanium
Weight, 5T, P, plastic
Weight, 5T, P, titanium
Depth rating, acetal plastic
Depth rating, 3AL–2.5V titanium
Depth rating, 6AL–4V titanium

2.1.1 Connectors and cables

Contact Function
1 Common
2 Voltage 0 signal
3 Voltage 0 common
Contact Function
4 English
J1 auxiliary differential input 0,1
Contact
4 Voltage 1 signal
5 Voltage 1 common
6 Auxiliary power out
J2 auxiliary differential input 2, 3
Contact
7.3, 2.3 kg
13.7, 8.6 kg
0.3, 0.1 kg
0.3, 0.4 kg
0.5, 0.1 kg
0.7, 0.3 kg
600 m
7000 m
10500 m
Function
Function
MCBH6MP
MCBH6MP
