Reload:
It is necessary to recharge the battery pack before use.
1.
Connect the plug of the wall adapter to the back of the desktop charger and
insert the adapter plug into the socket.
2.
Place the Li-ion battery pack or the radio complete with battery in the tray of
the desktop charger.
Make sure that the battery pack is inserted correctly.
During the charging phase, the LED of the desktop charger lights up red.
When the charge is complete, the LED lights up green.
Remove the radio or battery from the desktop charger.
Charging information
•
Once charging is complete, remove the battery from the charger.
•
Do not short-circuit the battery and do not throw it into fire.
•
We recommend turning off the radio while charging.
•
If the radio shows a charging defect, replace it.
•
The battery runtime is approximately 13 hours (5% transmission; 5% recep-
tion; 90% standby)
Installation:
Antenna Installation
36
Clip Belt Fastening
Battery Insertion
Connect PTT headset
Main keys:
MENU: allows you to activate menu operations, select the desired menus and
confirm the chosen parameters.
: by keeping it pressed for more than 2 seconds the channel and the frequen
cy will they will quickly move upwards; in scan mode, press it to scan
upwards.
: by keeping it pressed for more than 2 seconds the channel and the frequen
cy will they will quickly move upwards; in scan mode, press it to scan
upwards.
EXIT : press this button to exit the functions and settings.
Remove the Battery
