Installing the monitor

Installing the monitor
Operation
Unpack the product and check if the following contents have been included. The package content varies per item but always contains
the following:
WARNING! Do not use any unapproved accessories to ensure the safety and product life span. Any damages or injuries by
using unapproved accessories are not covered by the warranty.
Setup

Connecting the monitor

Before setting up the monitor, please read the supplied instruction manual and carefully follow the safety precautions. To protect
equipment, always turn off the source and monitor before connecting.
When setting up the monitor, pay close attention to your surrounding environment and ensure that the temperature and humidity
are within the specified specifications of that monitor. You will find these in the supplied manual. Once you have installed the
monitor in the desired position, please follow the steps below to connect it:
6. SET THE CORRECT INPUT
2. BNC, RCA, VGA, HDMI 1. DC 3. USB TOUCH
1. Firmly connect the power supply to the 5.5mm DC
port at the back of the display.
2. Connect the preferred video cable (e.g. HDMI, VGA,
RCA or BNC).
3. Connect the USB touch cable to the USB touch port.
4. Turn on the source providing the video signal.
5. Turn on the monitor.
6. Set the correct input channel using the INPUT button
on the included remote control, or by using the AUTO
button on the back of the display. Confirm your
selection by clicking OK on the remote control or +
on the operating buttons at the back of the display.
9 EN
