Overview (Fig. A)

1. External RC Antennas
2. Touchscreen
3. Indicator Button
[1]
4. Control Sticks
5. Internal Wi-Fi Antennas
6. Back/Function Button
7. L1/L2/L3/R1/R2/R3 Buttons
8. Return to Home (RTH) Button
9. Microphone
10. Status LED
11. Battery Level LEDs
12. Internal GNSS Antennas
13. Power Button
14. 5D Button
[1] DJI RC Plus is capable of supporting various DJI aircraft and the button functions vary depending on the aircraft. Read the user manual of the aircraft for
TM
more information on button functions.
Contact DJI Support or a DJI authorized dealer to replace the components of the remote controller if damaged. DO NOT
disassemble the remote controller without the assistance of DJI Support or a DJI authorized dealer.
Introduction
The DJI RC Plus remote controller features O3 Pro, the latest
version of DJI's signature OCUSYNC
technology, and can transmit a live HD view from the camera of
an aircraft to display on the touchscreen. The remote controller
comes with a wide range of aircraft and gimbal controls as well
as customizable buttons, which can easily control the aircraft and
operate the camera. The remote controller has a protection rating
of IP54 (IEC 60529). [2]
The built-in 7.02-in high brightness 1200 cd/m
resolution of 1920×1200 pixels. The Android operating system
comes with a variety of functions such as GNSS, Wi-Fi and
8
15. Flight Pause Button
16. C3 Button (customizable)
17. Left Dial
18. Record Button
19. Flight Mode Switch
20. Internal RC Antennas
21. microSD Card Slot
22. USB-A Port
23. HDMI Port
24. USB-C Port
25. Focus/Shutter Button
26. Right Dial
27. Scroll Wheel
28. Handle
Bluetooth. The remote controller has a maximum operating time
TM image transmission
of 3 hours and 18 min with the internal battery and up to 6 hours
when used with an external WB37 Intelligent Battery
[2] This protection rating is not permanent and may reduce over time after
[3] The maximum operating time was tested in a lab environment and is for
screen boasts a
2
[4] The WB37 Intelligent Battery is not included. Refer to the WB37
29. Speaker
30. Air Vent
31. Reserved Mounting Holes
32. C1 Button (customizable)
[1]
33. C2 Button (customizable)
34. Rear Cover
35. Battery Release Button
36. Battery Compartment
37. Rear Cover Release Button
38. Alarm
39. Air Intake
[1]
40. Dongle Compartment
41. 1/4" Threaded Holes
long-term use.
reference only.
Intelligent Battery Safety Guidelines for more information.
[3]
.
[4]
