Model assembly
4. Lock up the fasteners of supporting bars on fuselage and
main wing slots as shown.
5. Secure the supporting bars on the fuselage using the
included screws.
6. Secure the supporting bars on the main wing using the
included R clasps.
5
HKM3.0*10
Horizontal stabilizer installation
1. Slide the horizontal stabilizer spar into the fuselage.
2. Align and install the horizontal stabilizer over the spar and into the horizontal stabilizer slot of the fuselage.
