Specifications

Height / Width / Depth:
Weight:
Power supply:
Passive protection:
Maximum input power:
Cooling system:
Automatic Gain Control:
Metal Loss Correction (MLC):
Operational range:
Loop output:
Max. current:
Max. tension:
Loop resistance DC:
Connectors:
Frequency range:
Distortion:
Inputs:
Input 1
Input 2
Input 3
Link in
Outputs:
Headphones
Link connectors
Fault status connector
Loop connector
43 mm x 430 mm x 290 mm (19" 1HU)
3,8 kg
100 - 265 V AC 50 / 60 Hz
Fuse 5x20 T5A
< = 944 VA
Fanless
Speech-optimised, dynamic range: > 40 dB
0 - 4 dB / octave
0°C - 45°C, < 2000 m above sea level
<7 A RMS
34 V peak
0,5 - 3,0 Ω
2x NL4 Speaker Twist, assigned 1+/2+ and 1-/2-
80-6000 Hz (+/- 1,5 dB)
< 1% at rated power output, 1 kHz
5-20 mV / 2 kΩ / 48V optional (MIC)
180 mV - 4 V / 10 kΩ (Line)
Switchable between Mic und Line level, Combo-socket
5-20 mV / 2 kΩ / 48V optional (MIC)
180 mV - 4 V / 10 kΩ (Line)
Switchable between Mic und Line level, 3-point. Euroblock
plug
100V priority input, 2-point Euroblock plug
6,3mm jack socket, balanced
3,5 mm stereo jack socket
6,35 mm jack socket, balanced
3-point Euroblock plug
NL4 Speaker Twist, assigned 1+ parallel to 2+
1- parallel to 2-
