6.7 Tips for working with your hammer drill
6.7.1 Drilling concrete and masonry
•
Switch the Drill/Hammer drill selector switch
(3) to position B (Hammer drill).
•
Always use carbide drill bits and a high speed
setting for drilling into masonry and concrete.
6.7.2 Drilling steel
Switch the drill / hammer drill selector switch (3)
to position A (drill).
•
Always use HSS drill bits (HSS = high speed
steel) and a low speed setting for drilling
steel.
•
We recommend that you lubricate the hole
with a suitable cutting fluid to prevent unne-
cessary drill bit wear
6.7.3 Starting holes
If you wish to drill a deep hole in a hard material
(such as steel), we recommend that you start the
hole with a smaller drill bit.
6.7.4 Drilling tiles
•
To start the hole, switch the drill / hammer drill
selector switch (3) to position A (drill).
•
Switch the drill / hammer drill selector switch
(3) to position B (hammer drill) as soon as the
drill bit has passed through the tiles.
6.8 Drilling with the dust extraction system
(11)
Use the dust extraction system only for drilling
into concrete, bricks and masonry since wood
or plastic chips may block the extraction system.
Do not drill into metallic materials since hot metal
chips can damage the dust extraction system.
•
Fit the dust extraction system (11); see point
5.4.
•
Connect the dust extractor adapter (9) to the
suction hose of a suitable vacuum cleaner.
The vacuum cleaner must be suitable for
handling the substance that will be extracted.
Harmful dust must not be extracted using the
dust extraction system (11). Use on materials
containing asbestos is prohibited!
•
Set the required drilling depth (see point 5.2).
•
Mark the drilling position.
•
Tip: To prevent the wall being soiled, you can
mask the area around the transparent extrac-
tion opening with masking tape. Before you
use the masking tape, test whether the tape
can be removed easily from the wall again in
a place that it not easily visible.
•
Switch on the vacuum cleaner and place the
Anleitung_TE_ID_1050_CE_SPK7.indb 21 Anleitung_TE_ID_1050_CE_SPK7.indb 21
GB
transparent cover on the front of the dust ex-
traction system (11) over the drilling point so
that the drill bit is in front of the mark. Ensure
that the transparent cover is in contact with
the workpiece or wall.
•
Press the drill bit and machine gently against
the mark whilst the ON/OFF switch (5) is still
set to off.
•
Then drill the hole. See the instructions in
point 6.7 for more details.
•
The dust extraction system (11) must be clea-
ned after at least every 15 holes. For this pur-
pose remove the dust extraction system (11)
and the additional handle (8) as described in
points 5.4 and 5.1. Clean the dust extraction
system (11) and the interior of the additio-
nal handle (8) by carefully tapping them or
blowing them through with low pressure com-
pressed air.
•
If the extraction performance is poor, check
the dust extraction system (11) for possible
blockages or dirt.
•
The transparent cover is enclosed in a protec-
tive ring to prevent it from suffering damage.
This protective ring should be replaced as
soon as it is damaged or worn.

7. Replacing the power cable

If the power cable for this equipment is damaged,
it must be replaced by the manufacturer or its
after-sales service or similarly trained personnel
to avoid danger.
8. Cleaning, maintenance and
ordering of spare parts
Always pull out the mains power plug before star-
ting any cleaning work.
8.1 Cleaning
•
Keep all safety devices, air vents and the
motor housing free of dirt and dust as far as
possible. Wipe the equipment with a clean
cloth or blow it with compressed air at low
pressure.
•
We recommend that you clean the device
immediately each time you have fini-
shed using it.
•
Clean the equipment regularly with a moist
cloth and some soft soap. Do not use
