6. Operation

6.1 ON/OFF switch (Fig. 11/Item 5)
•
First fit a suitable drill bit into the tool (see
5.3).
•
Connect the mains plug to a suitable socket.
•
Position the drill in the position you wish to
drill.
To switch on:
Press the ON/OFF switch (5)
Continuous operation:
Secure the ON/OFF switch (5) with the locking
button (4).
To switch off :
Press the ON/OFF switch (5) briefl y.
6.2 Adjusting the speed (Fig. 11/Item 5)
You can infi nitely vary the speed whilst using the
tool.
•
Select the speed by applying a greater or les-
ser pressure to the ON/OFF switch (5).
•
Select the correct speed: The most suitable
speed depends on the workpiece, the type of
use and the drill bit used.
•
Low pressure on the ON/OFF switch (5): Lo-
wer speed (suitable for: small screws and soft
materials)
•
Greater pressure on the ON/OFF switch (5):
Higher speed (suitable for large/long screws
and hard materials)
Tip: Start drilling holes at low speed. Then increa-
se the speed in stages.
Benefi ts:
•
The drill bit is easier to control when starting
the hole and will not slide away.
•
You avoid drilling messy holes (for example
in tiles).
6.3 Preselecting the speed (Fig. 12/Item 6)
The speed controller (6) enables you to defi ne the
maximum speed.
•
Set the speed controller (6) to the required
position.
•
With the On/Off switch (5) pressed right in,
the motor will now run as quickly as was set
at the speed controller (6).
•
The setting can also be made during opera-
tion.
Anleitung_TE_ID_1050_CE_SPK7.indb 20 Anleitung_TE_ID_1050_CE_SPK7.indb 20
GB
Constant electronics
This tool is equipped with constant electronics.
With constant electronics, the set speed is kept
constant even when the tool is working under
load.
6.4 Clockwise/Counter-clockwise switch
(Fig. 11/Item 7)
•
Change switch position only when the drill is
at a standstill!
•
Switch the direction of the hammer drill using
the clockwise/counter-clockwise switch (7):
Direction
Clockwise (forwards and drill) Pushed in to the
Counter-clockwise (reverse)
6.5 Drill / hammer drill selector switch
(Fig. 12/Item 3)
•
Change switch position only when the
drill is at a standstill!
Drill:
Drill / hammer drill selector switch (3) in the drill
position. (Position A)
Use for: Wood, metal, plastic
Hammer drill
Drill / hammer drill selector switch (3) in the ham-
mer drill position. (Position B)
Use for: Concrete, rock, masonry
6.6 Defi ning the speed range (Fig. 13)
The speed selector switch (10) enables you to
work within a specifi c speed range.
Switch position, setting 1 (A)
Speed range: High torque, low speed
Switch position, setting 2 (B)
Speed range: Low torque, high speed
Important. Do not attempt to make this setting
whilst the drill is in use.
- 20 -
Switch position
right
Pushed in to the
left
