EnGLIsh
LED Worklight (Fig. A)

CAUTION: Do not stare into the LED. Serious eye injury
could result.
When the tool is activated by pressing the on/off button
LED worklight 8 will automatically turn on. The LED worklight will
turn off 60 seconds after the on/off button has been released.
To Maintain Safe Tool Control
• Make sure the work surface is free of nails or screws. Cutting
into a nail or screw may cause the tool to jump, damaging
the bit.
• Never operate the tool with one hand while holding the
workpiece with the other hand. Always clamp the material
and guide the tool with both hands.
• Do not cut material lying on a hard surface. Clearance
behind material to be cut must be allowed for
protruding bit.
• Disconnect battery from tool before making adjustments,
changing bits, or cleaning tool.
• Do not start the tool with bit engaged in the material. The
bit may grab the material.
Cutting a Hole for an Electrical Outlet (Fig. E)

WARNING: Shut off all live electric circuits to any areas
where cut-outs will be made.
1. Push any wiring deeply into the outlet box to avoid damage
from the cutting bit.
2. Before hanging the sheet covering the fixture box, mark the
approximate location of the center of the fixture box on the
wall board. Check the cutting bit depth against the side of
the board to be sure it will cut entirely through the material.
3. Tack the sheet in place with a few fasteners avoiding the
stud holding the fixture box. This allows the wall board to
flex slightly around the protruding fixture box.
4. Turn the cut‑out tool on. Holding the tool firmly with
both hands, plunge the bit straight into the center of the
fixture box.
5. Cut to the right until the bit reaches the inside edge of the
fixture box. Pull the bit out just enough it to clear the edge
of the fixture box. Plunge the bit in again, holding the bit
gently against the outside of the fixture box.
6. Follow the outside of the fixture box and complete the cut
counterclockwise, keeping slight pressure against the fixture
box. This will minimize wandering and give you a clean,
precise cut.
7. Remove the waste and dust from the fixture box. Finish
fastening the sheet of wall board.
MAINTENANCE
Your power tool has been designed to operate over a long
period of time with a minimum of maintenance. Continuous
satisfactory operation depends upon proper tool care and
regular cleaning.

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
36
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can cause injury.
The charger and battery pack are not serviceable.
1 , the
C
Lubrication
Your power tool requires no additional lubrication.
D
Cleaning

WARNING: Blow dirt and dust out of the main housing
with dry air as often as dirt is seen collecting in and around
the air vents. Wear approved eye protection and approved
dust mask when performing this procedure.

WARNING: Never use solvents or other harsh chemicals
for cleaning the non-metallic parts of the tool. These
chemicals may weaken the materials used in these parts.
Use a cloth dampened only with water and mild soap.
Never let any liquid get inside the tool; never immerse any
part of the tool into a liquid.

Optional Accessories


WARNING: Since accessories, other than those offered
by D WALT, have not been tested with this product, use
e
of such accessories with this tool could be hazardous.
To reduce the risk of injury, only D
accessories should be used with this product.
Consult your dealer for further information on the
appropriate accessories.
Tool Connect™ Chip (Fig. H)
Optional accessory

WARNING: To reduce the risk of serious personal
injury, turn unit off and remove the battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can cause injury.
Your tool is Tool Connect™ Chip ready and has a location for
installation of a Tool Connect™ Chip.
Tool Connect™ chip
application for your smart device (such as a smart phone or
tablet) that connects the device to utilize the mobile application
for inventory management functions.
Refer to Tool Connect™ Chip Instruction Sheet for
more information.
Installing the Tool Connect™ Chip
1. Remove the retaining screws
Connect™ Chip protective cover
2. Remove the protective cover and insert the Tool Connect™
Chip into the empty pocket
WALT recommended
e
23 communicates with an optional
20 that hold the Tool
into the tool.
19
13 .
