If the battery pack still fails to charge, send
•
the charger and charging adapter
•
and the battery pack
to our customer service center.
To ensure that the LI battery pack provides long
service you should take care to recharge it
promptly. You must recharge the battery pack
when you notice that the power of the cordless
hammer drill drops.
7.2. Inserting a tool (Fig. 4)
Important. Set the changeover switch (7) to its
center position whenever you carry out any work
(for example changing the tool, maintenance
work, etc.) on the equipment.
•
Clean the tool before fitting it and apply a thin
coating of bit grease to the tool shaft.
•
Turn and push the dust-free tool into the tool
chuck (1) as far as it will go. The tool will lock
automatically.
•
Check that the bit is locked in placed by
pulling on it.
7.3. Removing a tool (Fig. 5)
Pull back and hold the locking sleeve (2) and
remove the tool.
7.4 Screw/Drill/Hammer drill selector
switch (Fig. 6/Item 3)
Change the switch position only when the
equipment is at a standstill!
Drilling/screwdriving:
For drilling/screwdriving, press the button (C) on
the selector switch (3) and simultaneously turn the
selector switch (3) to position A.
Hammer drilling:
For hammer drilling, press the button (C) on the
selector switch (3) and simultaneously turn the
selector switch (3) to position B.
Important.
The 2nd gear must be selected for hammer dril-
ling. See point 7.7 Selecting the gear.
Anl_4513632.indb 15 Anl_4513632.indb 15
GB/IE
Important.
You only require slight contact pressure for ham-
mer drilling. Excessive contact pressure will place
unnecessary strain on the motor. Check drill bits
at regular intervals. Sharpen or replace blunt drill
bits.
7.5 Changeover switch (Fig. 7/Item 7)
Using the slide switch above the On/Off switch
you can select the direction of rotation of the
equipment and lock the equipment so that it can-
not be switched on accidentally. You can select
between clockwise and counter-clockwise rotati-
on. To avoid causing damage to the gearing, the
direction of rotation must only be changed when
the equipment is at a standstill. When the slide
switch is in the middle position, the On/Off switch
is blocked.
Important.
To avoid danger, the machine must only
be held using the two handles (9).
Otherwise you may suffer an electric shock if you
drill into electric cables!
7.6 On/Off switch (Fig. 7/Item 8)
Infi nitely variable speed control is possible with
the On/Off switch. The further you push the
switch, the higher the speed of the equipment.
7.7 Selecting the gear (Fig. 8/Item 4)
The gear selector switch (4) enables you to work
within a specifi c speed range.
Switch position setting 1
Speed range: High torque, low speed
Switch position setting 2
Speed range: Low torque, high speed
7.8 LED indicator for counter-clockwise/
clockwise (Fig. 8/Item 5)
The LED display for counter-clockwise/clockwise
(5) indicates the position of the changeover switch
(7).
Blue LED is lit: Clockwise
Red LED is lit: Counter-clockwise
