Note regarding screws with thread-locking fluid:
Screw in the screws as far as they will go and tighten
them with the specified torque.
Preparation installation only by specialist dealers.

Required tools

• Torx spanner TX30/TX40
• Allen key size 3
• Torque spanner
- Extension
- Size 17
- TX30
- TX40
Installation
See page 16.
X

TRANSPORT AND STORAGE

Store the rear carrier system / accessories in a dry, clean
X
and frost-free place.

CLEANING AND MAINTENANCE

Adjust buffer points in the following cases:
X
- Rear carrier collides with Backrack/vehicle when
swivelled upwards
- Loaded rear carrier runs past retainer and does not
lock
- Rear carrier does not reach second locking stage
- Rear carrier sits twisted on mechanism (collision of
inner retainer with inner lock bracket)
Tighten the fastening screws at regular intervals.
X
Regularly clean the rear carrier system/accessories with
X
warm water and suitable cleaning agents, at the latest
after exposure to salt water. Do not use aggressive
cleaning agents.
Do not clean the rear carrier system/accessories in car
X
washes.

DISPOSAL

All components of the rear carrier system/accessories are
100% recyclable and can be handed over to appropriate
collection points for recycling.
Dispose of luminaires/lamps properly as electronic
X
waste.
