A
DANGER:
The "U" bracket is provided with two secondary safety anchoring points (D).
You can also use a safety cable (not supplied) whenever you install a SHADOW speaker. The safety cable must be
fixed by means of an M8 eyebolt in the insert located at the rear of the loudspeaker (fig 3).
SERIE 108
17
A
fig 3
D
B
C
SERIE 112 / 114
INSTALLATION
C
fig 1
15°
10°
10°
fig 2
DANGER:
Lifting and anchoring carried
out using eyebolts must be
carried out allowing any tie
rods (ropes, chains, and
accessories) connected to
t h e m f u l l f r e e d o m o f
m o v e m e n t a n d s e l f -
positioning.
Incorrect or improper use can
cause serious damage to
p e o p l e a n d n e a r b y
equipment.
Never exceed the maximum
workload that the eyebolt can
sustain.
B
