4. Plug the charger plug into an electrical outlet
and wait for a while. The LED indicators on the
charger (25) will lighten up and show the char-
ger status.
The charger has 2 LED indicators (25) which indi-
cate the status of the charging process:
Red LED Status Green LED status
Off Off
Off On
On Off
• Fully charging the 2Ah battery may take up to
60 minutes.
• Fully charging the 4Ah battery may take up to
120 minutes.
After the battery is fully charged remove the char-
ger plug from the outlet and remove the battery
from the charger.
When the machine is not being used over a
longer period of time it is best to store the
battery in charged condition.
Assembly of the filter (Fig. E - G)
1. Remove the top section (7) of the container (8)
as shown in Fig. E.
2. Assemble the filter. Ensure to mount the correct
filter, depending on the application:
• For dry vacuum cleaning, carefully slide
the HEPA filter (14) over the filter cage (15)
making sure the entire cage (15) is covered
as shown in Fig. F1.
• For wet vacuum cleaning, carefully slide
the foam filter (13) over the filter cage (15)
making sure the entire cage (15) is covered
as shown in Fig. F2.
3. Place the top section (7) on the container (8) as
shown in Fig. E.
WWW.VONROC.COM
Connecting the hose (Fig. D1, D2).
• For vacuuming (Fig. D1), connect the suction
hose (12) to the vacuum port (10).
• For blowing (Fig. D2), connect the suction hose
(12) to the blowing port (9).
Connect the desired nozzle.
Triangular nozzle (18)
The triangular nozzle is designed for domestic wet
Charger status
and dry vacuuming in, for example, the house, work
No power
room, or garage.
Standby mode:
Crevice nozzle (19)
- No battery is
The crevice nozzle is designed for domestic wet
inserted or,
and dry vacuuming, edges and other areas that are
- Battery inserted
difficult to access.
but charging has
finished
Car vacuum tool (20)
Battery charging in
The brush is designed to vacuuming solids from
progress
small areas. For example from car seats.
Power tool adapter (21)
Adapter for connecting suction hose with a power
tool.
4. OPERATION
Switching the machine on/off
• Press the power switch (1) into the "ON/I" posi-
tion to start your vacuum cleaner.
• Press the power switch (1) into the "OFF/0"
position to switch off your vacuum cleaner.
Dry vacuuming (Fig. D1, G)
If the vacuum cleaner accidentally tips over,
the shut-off float (16) mechanism may
cover the motor vacuum port and stop the
suction. If this happens, simply stand the
cleaner upright and turn it off until the float
(16) returns to its normal position.
Do not vacuum without a filter!
Clean the HEPA filter (14) regularly to
maintain the suction power.
To avoid the HEPA filter (14) becoming
clogged, we recommend the additional use
of a dust collection bag (17).
