Overview Drawing; Assembly Instructions - Mvs In Motion Moves Oxycycle 2 Bedienungsanleitung

Overview Drawing & Parts List
10
18
20
9
13
21
34
26
19
27
21
28
1
16
7
11
12
3
12
(24) Bolt M8 x M12 (31) Spring Washer
Part # Description
1 Controller
2 Rear Stabilizer 380
3 Front Stabilizer 220
4 Main Frame
5 Magnet Bracket
6 Right Cover
7 Left Cover
8 Right Crank
9 Left Crank
10 Plastic Cap
11 PCB Support
12 Stabilizer End Cap
13 Motor
14 Square Sensor
15 Square Magnet
16 Power Control Board
17 Right Foot Pedal
18 Left Foot Pedal
4
12
2
35
23
12
30
30
23
22
14
29
25
15
26
31
5
8
24
4
32
31
19
24
20
10
33
6
Wrench Allen Wrench
Q'ty Part # Description
1 19 Bolt M5x40mm
1 20 Bolt M8x20mm
1 21 Nut M5
1 22 Bolt M5x10mm
1 23 Bolt M6x12mm
1 24 Bolt M8x12mm
1 25 Screw ST2.9x10
1 26 Screw ST4.2x15
1 27 Controller Bracket A
2 28 Washer
6 29 Spring Washer
4 30 Spring Washer
1 31 Spring Washer
1 32 Controller Bracket B
1 33 Right Handgrip Pedal
1 34 Left Handgrip Pedal
1 35 AC Power Cable
1 36 Non-slip Mat

Assembly Instructions

1
36
17
3
Q'ty
5
2
2
2
2
6
6
2
11
1
1. Hold the unit in an upright position. The controller side facing up and the AC power cable
side facing down. Insert the front stabilizer (3) into the main frame (4).
2
2. Attach the front stabilizer (3) to the main frame (4) with three bolts (24) and three spring
2
washers (31).
6
3. Insert the rear stabilizer (2) into the main frame (4).
6 4. Attach the rear stabilizer (2) to the main frame (4) with three bolts (14) and three spring
washers (31).
1
5. Connect the left foot pedal (18) to the left crank (9) assembly. Thread it into the crank
1
assembly in a counter-clockwise direction with the tool provided. (See figures 5 and
1 6). Connect the right foot pedal (17) to the right crank (8) assembly by threading it in
a clockwise direction. Note: The left/right pedals and left/right cranks are marked with
1
"L" and "R" (left and right)
1
2
4
6
5
