5.1
The buttons of LED wire controller
5.2 When the heat pump is running, the LED display shows the water inlet temperature.
LED 1 is on when compressor is running.
LED 2 is on if trouble.
5.3 Turn on/off the heat pump
Press to turn on the heat pump, the LED display shows the water setting temperature for 5s, then show
water inlet temperature.
press again to turn off the heat pump.
5.4 Set the water outlet temperature
Press or
Press to save the setting then exit.
5.5 parameter checking
Parameter
Ambient temperature
Water temperature
，it will enter the parameter checking, Press
Press
again, it will show the measured value. Lastly press
5.6 Trouble shooting.
directly to adjust water outlet temperature (range:.10—42℃)
Code Unit range
d0 0—99
℃
d1 0—99
℃
Remark
It will flash and show oU if out of range
It will flash and show oU if out of range
or
to save the setting then exit.
9
to choose the code d0/d1,，press
