Danieli Automation - ID6100
4 4 . . P P H H O O T T O O C C E E L L L L C C O O N N N N E E C C T T I I O O N N S S
The connection and signalling devices are located on the rear end of the photodetector.
4 4 . . 1 1 E E l l e e c c t t r r i i c c c c o o n n n n e e c c t t i i o o n n s s
Fig.3(1). MIL type, 19 terminal connector.
To comply with the isolation requirements between the analog and digital circuits, do not connect
0V and 0VE together.
Connector pins
J
Weldings side view
NPN output
P
L
IPO
0V
U
M A
L
N
K
B
U
T
V
P
J
C
S R
D
H
A
POS
G
E
F
F
0V
K
PNP output
test
C
2 2
+24 Vdc
0 Vdc
P P i i n n
S S i i g g n n a a l l
F F u u n n c c t t i i o o n n
J
+24VE
24 V DC power supply
C
0VE
0 V DC power supply
P
PFA/
Material Presence NPN digital output
K
PFA
Material Presence PNP digital output
A
POS
Loop position analog output (voltage)
L
IPO
Loop position analog output (current)
U-F
0V
0 Volt reference for POS and IPO out
E
Test
0 VDC test
G
Test
24 VDC test
4 4 . . 2 2 S S i i g g n n a a l l l l i i n n g g d d e e v v i i c c e e
Fig.3 (2). The green LED indicator light, indica-
tes "hot material present".
Pag. 18
+24 Vdc
Material
Presence LED
2
19 pole MIL
male connector
250 Ohm
1
max
Cooling system
connectors
3
0 Vdc
3 3
4 4 . . 3 3 C C o o o o l l i i n n g g d d e e v v i i c c e e
Figure 3 (3) 1/4" GAS connectors for the input
and outlet of the fluid cooling circuit equipping
the photodetector.
2 2 E E l l e e c c t t r r i i c c a a l l
c c o o n n n n e e c c t t i i o o n n s s o o f f t t h h e e
p p h h o o t t o o d d e e t t e e c c t t o o r r . . U U s s e e
s s h h i i e e l l d d e e d d c c a a b b l l e e f f o o r r
a a n n a a l l o o g g o o u u t t p p u u t t
s s i i g g n n a a l l s s . .
3 3 R R e e a a r r v v i i e e w w o o f f t t h h e e
p p h h o o t t o o d d e e t t e e c c t t o o r r , , w w i i t t h h
t t h h e e c c o o n n n n e e c c t t i i o o n n a a n n d d
s s i i g g n n a a l l l l i i n n g g d d e e v v i i c c e e s s . .
5 5 . . P P H H O O T T O O D D E E T T E E C C T T O O R R C C O O N N F F I I G G U U R R A A T T I I O O N N
It is possible to configure the following aspects:
The range of the analog outputs in terms of
voltages and currents (POS or IPO).
Vertical angle of the visual field
(30° or 45°).
Automatic sensitivity control.
Single or multiple bar detection mode.
Configuration is efected by means of DIP-swit-
ches located inside the photo-detector, which
can be accessed by removing the side cover.
There are two banks of DIP-switches, marked A
and B (see figure 4).
DIP-SWITCH A
DIP-SWITCH B
ON
ON
1 2 3 4 5 6 7 8
1 2 3 4 5 6 7 8
4 4 D D I I P P - - S S W W I I T T C C H H p p o o s s i i t t i i o o n n i i n n s s i i d d e e t t h h e e I I D D 6 6 1 1 0 0 0 0 p p h h o o t t o o c c e e l l l l . .
5 5 . . 1 1 P P O O S S a a n n a a l l o o g g o o u u t t p p u u t t s s e e t t t t i i n n g g s s ( ( v v o o l l t t a a g g e e o o u u t t p p u u t t ) )
The following table describes how to set Bank A
DIP-Switches to select the range of POS analog
output.
O O u u t t p p u u t t r r a a n n g g e e
S S w w i i t t c c h h : : 1 1
S S w w i i t t c c h h : : 2 2
S S w w i i t t c c h h : : 7 7
0 ÷ +10V
ON
OFF
OFF
+10 ÷ 0V
ON
OFF
ON
-5 ÷ +5V
ON
ON
OFF
+5 ÷ -5V
ON
ON
ON
-10 ÷ +10V
OFF
ON
OFF
+10 ÷ -10V
OFF
ON
ON
Instruction Manual
5 5 . . 2 2 I I P P O O a a n n a a l l o o g g o o u u t t p p u u t t s s e e t t t t i i n n g g s s ( ( c c u u r r r r e e n n t t o o u u t t p p u u t t ) )
The following table describes how to set Bank A
DIP-Switches to select the range of IPO analog
output.
O O u u t t p p u u t t r r a a n n g g e e
S S w w i i t t c c h h : : 3 3 S S w w i i t t c c h h : : 4 4 S S w w i i t t c c h h : : 5 5 S S w w i i t t c c h h : : 7 7
4 ÷ 20mA
ON
OFF
OFF
OFF
20 ÷ 4mA
ON
OFF
OFF
ON
0 ÷ 20mA
OFF
ON
ON
OFF
20 ÷ 0mA
OFF
ON
ON
ON
NOTE: The loop detector is factory set for 0-+10 V voltage
output and 4-20 mA current output.
If the detector installed in the upright position (mounting
pod down), 0 V (or 4 mA) corresponds to the presence of
material at the lowest position, and 10 V (or 20 mA) corre-
sponds to the presence of material at the highest position.
In the absence of any material, the digital output is disac-
tivated, while the analog output assumes the value of the
top end of the set scale (100%), as if a bar was present
and in the highest position.
5 5 . . 3 3 V V i i e e w w i i n n g g a a n n g g l l e e s s e e t t t t i i n n g g
The following table describes how to set the
Bank A DIP-Switches to select the width of the
viewing angle.
V V i i e e w w i i n n g g A A n n g g l l e e
S S w w i i t t c c h h : : 8 8
30°
OFF
45°
ON
5 5 . . 4 4 A A u u t t o o m m a a t t i i c c s s e e n n s s i i t t i i v v i i t t y y c c o o n n t t r r o o l l
With the function OFF (disabled) the scan perio-
dof the CCD photosensor (and therefore the
refresh rate of the loop position output) is fixed.
With the function ON (enabled) the scan period
adapts automatically to the intensity of the
radiation detected (and hence the temperature
of the material)
Pag. 19
