Screw in the lower door bolt, rotate the door
and position it onto the bolt so that the bot-
tom hinge together with the screwed-in bolt
supports the door; the door must be positio-
ned so that the hole fits over the bolt. The ot-
her person must now hold the door in position.
Place the top bolt into the recess provided at
the top of the door, position the door between
the two hinges, and screw in the bolt through
46
the hinge from above.

Setting up the appliance

As soon as they have been unpacked, all parts
must be checked for any damage caused du-
ring transport. Damage to the packaging shall
not be regarded as a product fault. If there is
cause for complaint, please contact our cus-
tomer services immediately.
The appliance must be set up and connected
in accordance with this user manual and ins-
tallation instructions.
The conditions of supply of local electricity
providers must be complied with in addition to
the statutory national provisions.
During transport, oil contained in the conden-
ser may be displaced into the cooling system.
For this reason, the appliance should be left for
at least one hour after set-up before com-
mencing operation.

The appliance must be positioned so that it
stands straight horizontally and vertically.
WARNING: The appliance must not stand at an
angle, otherwise there is a risk that the door
will not close properly, water will run out, and/
or the plants will dry out.

Before moving the appliance, whether to a
new location or to adjust its position, you must
ensure that it is disconnected from the mains
and does not contain any water.
Feet
The appliance features 4 feet, which serve
to ensure the correct horizontal and vertical
alignment of the appliance.

Electrical connection

The appliance is switched on as soon as it has
been connected to an intact socket using a
cold appliance plug. There is no additional On/
Off button.
The appliance must only be operated with 220
– 240 V and 50 Hz AC power through a socket
that has been earthed and fused in accordan-
ce with the regulations. The socket fuse must
trip when the current is between 10 A and 16 A.
The socket must remain easily accessible even
after set-up of the appliance.
The appliance must not be connected to a
multi-plug or stand-alone inverter (conversion
from direct current to alternating current).
Only extension cables or distribution blocks
provided by Agrilution are permitted for use.

Saving energy

Sufficient ventilation must be ensured at all
times.
Do not expose the appliance to direct sunlight
or place it near sources of heat.
Energy consumption will depend on the ins-
tallation conditions, particularly the ambient
temperature.
Installation options
Free-standing

The appliance must only be set up free-
standing on the ground or on equipment
provided by Agrilution. Risk of the appliance
tipping or falling over!
Suspended integrated appliance

The rear panels of kitchen carcasses above
must be at least 55 mm away from the wall
behind to enable warm air to escape!
Undercounter integrated appliance (with
continuous plinth)

The worktop must feature a ventilation vent
towards the back of at least 0.2 m2 (opening)!
Up-to-date illustrations and notes relating to
the integration variants can be found in the
app and at our website.
