4. Technical data

Engine displacement
Maximum engine capacity
Bar length
Cutter rail length
Chain pitch
Chain thickness
Idling speed
Maximum speed with cutting equipment
Tank capacity
Oil tank capacity
Anti-vibration function
Chain wheel teeth
Chain brake
Clutch
Automatic chain lubrication
Low-kickback chain
Net weight without chain and chain bar
Net weight (dry)
Fuel consumption (specific)
L sound pressure level
pA
K uncertainty
pA
L sound power level
WA
K uncertainty
WA
Vibration a (front handle)
hv
K uncertainty
hv
Vibration a (rear handle)
hv
K uncertainty
hv
Chain type OREGON 91VG053X (91P053X)
Bar type
Spark plug
41 cm 3
1.5 kW
33.5 cm
14" (35 cm)
(3/8"), 10 mm
(0.05"), 1.27 mm
3300 ± 300 rpm
11000 rpm
260 ml
210 ml
Yes
6 x 9.525 mm
Yes
Yes
Yes
Yes
4.5 kg
5.4 kg
560 g / kWh
99 dB(A)
3 dB(A)
114 dB(A)
1.5 dB(A)
max. 6.5 m/s 2
1.5 m/s 2
max. 6.0 m/s 2
1.5 m/s
2
OREGON 140SDEA041
L8RTF

5. Before starting the equipment

Important: Do not start the engine until the saw
is fully assembled.
Important: Wear protective gloves at all times
when handling the chain.
5.1 Fit the chain bar
To ensure that the bar and the chain are supplied
with oil, USE ONLY THE ORIGINAL BAR. The oiling
hole (Fig. 2/Item A) must be kept clear of dirt and any
build-up of residue.
1. Make sure the Chain brake lever is pulled back
into the DISENGAGED position (Fig. 3A)
2. Remove the bar fastening nut (B). Remove the
cover (Fig. 3B).
3. Run the adjustment screw (D)
COUNTERCLOCKWISE until the TANG (E)
(projecting prong) is to the end of its travel toward
the clutch drum and sprocket (Fig. 3B/3C).
4. Fit the open end of the chain bar over the die bar
pins (F) (Fig. 3C/3D).
5.2 To install saw chain
1. Spread chain out in a loop with cutting edges (A)
pointing CLOCKWISE around loop (Fig. 4A).
2. Slip the chain around the sprocket (B) behind the
clutch (C). Make sure the links fit between the
sprocket teeth (Fig. 4B).
3. Guide the drive links into the groove (D) and
around the end of the bar (Fig. 4B).
NOTE: The saw chain may droop slightly on the lower
part of bar. This is normal.
4. Pull the chain bar forward until the chain is closely
seated. Make sure that all the drive links are in the
groove of the bar.
5. Fit the clutch cover and fasten it with 2 screws.
Make sure that the pivot (Fig. 3C/Item E) fits into
the chain bar (Fig. 3D/Item G). The chain must
not slip off the bar when you do this. Tighten the
two nuts by hand and then follow the instructions
for adjusting the tension in ADJUSTING THE
CHAIN TENSION.
