EN
Specifications
Model
Operating Temperature
Transmission System
Operation Frequency Range 2.400-2.4835 GHz; 5.725-5.850 GHz*
Transmission Power (EIRP)
Wi-Fi
Protocol
Operation Frequency Range 2.400-2.4835 GHz; 5.150-5.250 GHz; 5.725-5.850 GHz*
Transmission Power (EIRP)
Bluetooth
Protocol
Operation Frequency Range 2.400-2.4835 GHz
Transmission Power (EIRP)
* 5.8 GHz is unavailable in some countries due to local regulations.
CHS
技术规格
型号
工作环境温度
图传方案
工作频率
发射功率（EIRP）
Wi-Fi
协议
工作频率
发射功率（EIRP）
蓝牙
协议
1
RM330
-10° to 40° C (14° to 104° F)
When used with different aircraft hardware configurations,
DJI RC Remote Controllers will automatically select the
corresponding firmware version for updating and support
the following transmission technologies enabled by the
hardware performance of the linked aircraft models:
a. DJI Mini 3 Pro : O3
b. DJI Mavic 3 : O3+
2.4 GHz: <26 dBm (FCC), <20 dBm (CE/SRRC/MIC)
5.8 GHz: <26 dBm (FCC), <23 dBm (SRRC), <14 dBm (CE)
802.11a/b/g/n
2.4 GHz: <23 dBm (FCC); <20 dBm (CE/SRRC/MIC)
5.1 GHz: <23 dBm (FCC/CE/SRRC/MIC)
5.8 GHz: <23 dBm (FCC/SRRC); <14 dBm (CE)
Bluetooth 4.2
<10 dBm
RM330
-10℃至 40℃
配合不同的无人机硬件，DJI RC 都会进行自适应选择对应
的固件，以释放无人机端的硬件性能，可达到以下图传标准：
a.DJI Mini 3 Pro：O3
b.DJI Mavic 3：O3+
2.400-2.4835 GHz；5.725-5.850 GHz*
2.4 GHz：<26 dBm (FCC), <20 dBm (CE/SRRC/MIC)
5.8 GHz：<26 dBm (FCC), <23 dBm (SRRC),
<14 dBm (CE)
802.11a/b/g/n
2.400-2.4835 GHz; 5.150-5.250 GHz; 5.725-5.850 GHz*
2.4 GHz：<23 dBm (FCC)；<20 dBm (CE/SRRC/MIC)
5.1 GHz：<23 dBm (FCC/CE/SRRC/MIC)
5.8 GHz：<23 dBm (FCC/SRRC)；<14 dBm (CE)
蓝牙 4.2
