Technical Data; Troubleshooting - power LOG 10t Originalbetriebsanleitung

Technical data

Type
Splitting wedge force
Max. log length
Log diameter
Splitting wedge travel
Downward travel speed
Upward travel speed

Troubleshooting

Failure
The log cannot be split
(poor performance)
Irregular movement or strong
vibrations of the splitter co-
lumn when it is moving down
The splitter column cannot
be retracted
The motor is running but
the splitter column does not
move
The motor is not running
32
Powerlog 10t
100 kN (10t) ±10%
1300 mm
min. 120 mm – max. 400 mm
≈ 515mm
approx. 0.05 m/sec
approx. 0.17 m/sec
Possible cause
Incorrectly positioned log
The log size exceeds the allowed
dimensions
The splitting wedge does not split
Low oil pressure
The releasing rod linkage is bent
(the hydraulic control lever is not
fully depressed)
A cable longer than 10 meters or a
cable with small cross-section wire
is used
Air in the system
The splitter column is not properly
lubricated.
failure in the hydraulic system
The motor is running in the wrong
direction
Power supply failure
The three-phase motor is running
with 2 phases.
Defective power supply cable
Defective motor
Hydraulic oil (max.)
Hydraulic pressure
Motor output
Power supply connection
Dimensions
Weight
Remedy
Turn and reposition the log in the
machine.
Use a log of recommended dimen-
sions.
Sharpen the splitting wedge and
check the cutting edge for wear or
notches.
Check the oil level. If the problem
persists, contact an authorised
service centre.
Have the rod linkage repaired and
adjusted by the manufacturer or an
authorised service centre.
Use the correct cable according to
the specifi cation.
Check the oil level.
Lubricate the splitter column with
grease or oil spray. If the problem
persists, contact an authorised
service centre.
Contact an authorised service centre.
Check the three-phase motor for the
correct direction of rotation. Change
the direction of motor rotation.
Check the protection.
Have the fuse and power supply
checked by an electrician.
Replace the power supply cable.
Contact an authorised service centre.
10 litres
21.4 MPa (214 bar)
P1 4.0 kW (S6 40%)
400 V 3~ 50 Hz, 16 A slow
Depth 580 mm x Width
530 mm x Height 1530
mm
approx. 175 kg
