7 Charge the product battery
Important:
– Do not charge the power bank using the USB-A ports on a computer. The current supplied by
these ports may not be sufficient and can damage the computer.
– To prolong the battery life, it is recommended to fully charge the battery every 3 - 6 months.
– Do not jump start the vehicle while charging the batteries!
■
The battery level indicators will indicate the level of charge:
(● = 25%, ●● = 50%, ●●● = 75%, ●●●● = 100%).
■
To recharge the battery, connect one end of the charging cable to a power supply and the other end
TM
to the USB-C charging input Input on the product.
– Battery level indicators flashing: charging in progress
– Battery level indicators constant on: fully charged.
8 Power bank
P :
RECONDITIONS
a
To use this product as a power bank you will need a suitable charging cable.
1. Connect one end of the charging cable to your mobile device, and the other end to a charger output
on the product.
2. Long press the button to start charging.
9 LED light
■
Long press the button to switch the light ON/OFF.
■
Press the button repeatedly to cycle through modes: ON (white) → SOS (white) → ON (red) →
Strobe (red).

10 Air compressor

10.1 Settings
Button Action Description
Short press Press repeatedly to toggle through pressure pre-sets:
(car),
setting mode).
Press and hold When the pressure unit flashes, press repeatedly to select a pressure
unit: PSI, BAR, KPA, Kg/cm
Short press Increase / decrease the air pressure level.
/
Short press Start/stop the compressor.
Tip:
Select a pressure pre-set, then press
10.2 Inflation
Important:
■
Inspect the product before inflating. Check the valve and the air hose is not damaged.
■
Do not bend or restrict the air hose while the compressor is in use.
■
Risk of damage due to water ingress Do not use in rain or wet conditions.
■
In case of an electrical or mechanical fault, immediately switch OFF and disconnect the product.
■
Only use on inflatable items (e.g. tires, balls, air bed). Take extra care not to over-inflate.
■
Please refer to your vehicle handbook for the correct tire pressure required for your vehicle.
■
Carefully observe the tire pressure and air pressure units when using "manual setting mode".
Over inflating can cause an object to burst.
■
Allow a vehicle tire to cool down before inflating.
P :
RECONDITIONS
a
You have read all the safety information and know the correct inflation pressure for the task.
1. Press and hold to switch the power ON.
2. Make sure the correct pressure unit is selected.
3. Select a pressure level pre-set and/or manually adjust the air pressure level.
4. (If needed) attach a valve connector to the end of the air hose.
5. Connect the air hose to the air hose connector Air Hose Connector outlet on the product.
6. Lay the product flat on the ground.
7. Connect the air hose to the valve on the object you are inflating.
à The object's pressure level will show on the display.
5
(motorcycle), (bicycle), (ball), no icon (manual
2
.
/ to fine tune the air pressure level.
8. Press to start/stop the compressor.
9. Press and hold to switch the power OFF.
10. Disconnect the air hose.
Important:
Prevent overheating. For every 8 minutes of continuous use, the product must cool down for 5
minutes before using again.
11 Quick starting system
Important:
■
Only use the included starter cables.
■
Clean corroded or dirty vehicle battery terminals before connecting the cables.
■
Do not use if a cable or clip is damaged.
■
To prevent damage to the product, only use with 12 V vehicle onboard systems.
■
Never short circuit the two pole terminals e.g. Do not clamp both cables together or to the same
piece of conductive material.
11.1 Before jump starting the vehicle
■
Prepare vehicle for ignition. Place gear in park/neutral and engage the emergency brake.
■
Switch off all vehicle electronics e.g. air conditioner, heater, radio, and lights.
■
Make sure there is at least 50% charge in the starter.
11.2 Normal starting method
Important:
If ignition fails after 3 attempts, disconnect the quick start system, wait 5 mins then try the
ing method [} 5].
1. Connect the starter cables plug to the starter cables socket.
2. Clip the red and black cables to the electrodes of the vehicle battery in the following sequence.
– Red clamp to positive (+).
– Black clamp to negative (-).
3. Check the starter status indicator:
– Alternating red/green flashing (normal) → proceed to step 4.
– Other LED status: see section Status indicators
4. Attempt to start the vehicle.
– Do not start the ignition for more than 3 secs at a time.
– Allow the starter to cool down for 30 secs between each start attempt.
– Maximum 3 attempts within 2 mins.
5. If the engine starts, disconnect the black terminal followed by the red terminal. Replace the sockets
cover.
Let the vehicle run for approx. 30 mins to recharge the battery.
11.3 Force starting method
Important:
Use this method if the normal starting method fails.
If ignition fails after 3 attempts, disconnect the quick start system and contact a specialist workshop.
1. Connect the starter cables plug to the starter cables socket.
2. Clip the red and black cables to the electrodes of the vehicle battery in the following sequence.
– Red clamp to positive (+)
– Black clamp to negative (-)
3. Check the starter status indicators:
– Alternating red/green flashing (normal) → proceed to step 4.
– Other LED status: see section Status indicators
4. Press and hold the Force Start Button for 3 secs until the status LED lights solid green.
– Start the vehicle within 30 seconds after the LED lights solid green.
– Attempt to start the vehicle. Do not start ignition for more than 3 secs at a time.
– Allow the starter to cool down for 30 secs between each start attempt.
– Maximum 3 attempts within 2 mins.
5. If the engine starts, disconnect the quick start system and replace the sockets cover.
Let the vehicle run for approx. 30 mins to recharge the battery.
Force start-
[} 6].
[} 6].
