An increase in pressure is only temporary. The size of the Air Buffer is changed by the amount
of air. Please note that the size must not exceed a diameter of 14cm.
The larger the Air Buffer, the harder the movements of the Flow Perfect
Air Buffer, the softer the movements of the Flow Perfect
performance and comfort.
We recommend that you make an initial personal adjustment before using the device for the
first time. This adjustment can be made at any time during use, i.e. also later. When delivered,
the Air Buffer is filled with air ready for use.
This is how to change the size of the Air Buffer - the following steps are to be carried out
one after the other:
Step 1 - Make the Air Buffer Neutral Size
1.) Please place the Flow Perfect
The Flow Perfect
2.) Remove the valve needle from the handle of the air pump
3.) Moisten valve needle
4.) Insert the valve needle into the needle valve, do not apply pressure to the air buffers.
Please insert the valve needle straight into the valve, i.e. without lateral movement and
perpendicular to the surface of the air buffers.
5.) Air escapes from the Air Buffer.
6.) As soon as you hear no more escaping air, please pull the valve needle out of the needle
valve again. Do not apply pressure to the air buffer.
7.) Now the Air Buffer is a neutral size.
Step 2 - Adjust the size of the Air Buffer
8.) Screw the valve needle onto the air pump
1.) Push the air pump piston rod all the way in
2.) Moisten valve needle
3.) Insert the valve needle into the needle valve, but do not apply pressure to the air buffer.
4.) Now perform as many pumping movements as you need. If the Flow Perfect
hard for you, then select 3 pump strokes. If the Flow Perfect
for you, then select 7 pump strokes.
5.) Important: Do not pull out the piston rod of the air pump during the last pumping stroke,
but hold it in the inserted state (otherwise air could escape).
6.) Please pull the valve needle with the air pump out of the needle valve again.

Replace Air Buffer

This is how the air buffers are replaced:
For this you need a screwdriver size TX20 (not included).
Note: Please wear gloves to protect hands from injury.
Place the Flow Perfect
plates are accessible. The cover plates are fixed in the base unit with six 15.5 x 3 screws.
Step 1 - Disassemble Air Buffer
1.) Remove the cover plates by first loosening the six screws and then lifting off the cover
plate. Repeat this procedure for all cover plates.
2.) Please turn the Flow Perfect
3.) Remove the valve needle from the air pump handle.
4.) Wet the valve needle.
Page 11 From 14
® on a firm surface so that the air buffers are facing upwards.
® is therefore 'upside down'.
® on a firm base so that the Air Buffer is on the base and the cover
® so that the Air Buffer is accessible to you.
V06-22
® feel. The smaller the
feel. You have the choice between
®
® Flow Perfect
® was too
® was too soft
