TECHNICAL DATA

• Power source:
14.8 V ( 2x LiPo 7.4 V )
14.4 V ( 2x NiMH 7.2 V )
• Brushed motor:
7.2–14.8V
• T-plug connector system
• Models:
1/10 and 1/8 On-Road / Off-Road
INSTALLATION
• place vehicle on the start box.
• the engine's flywheel must be positioned exactly above the
start box's flywheel.
• adjust the start box's rear support – can also be rotated by 180°
• fasten the centring pin in such a way that the vehicle has a
secure hold
•

INSERTING THE BATTERIES

GB // 8
• Length: 360 mm
125 mm
• Width:
• Height: 120 mm
• Weight: 1700g
• mount the front centring pin
find a suitable place on the vehicle (in most cases the front control
arms are suitable for this)
Fix and secure the batteries using the slotted hole:
IMPORTANT/ATTENTION!!
Please be informed, when using rechargable lithium batteries
(Li-Po), please be ensure the Startbox for Nitro Glow engines
does not have an lithium undervoltage protection. In the event
of deep discharge, we do not accept any liability for a defective
battery. We recommend a „Lipo Alarm" this sold separatly (it´s
not included), please contact your dealer.
