Bertilo Concept Montageanleitung Seite 3

BCON1(NF/AN)
ID Details in mm (Tolerance/Toleranz ...-+ 2mm)
16 x 1109 x 2300
1112
58 x 554 x 1953
352
58 x 228 x 2218
359
58 x 304 x 2218 Right side / die Recht
361
44 x 690 x 2300
363
32 x 920 x 1868
34
40 x 80 x 2218
902
40 x 60 x 1878
944
28 x 28 x 2140
1098
40(41) x 60(41) x 500
857
1125
19 x 90 x 2150
1086
19 x 90 x 1235
Floor panel
MFP
Pcs. ID Details in mm (Tolerance/Toleranz ...-+ 2mm)
58 x 1109 x 1953
351
x 2
58 x 120 x 1953
358
x 2
58 x 304 x 2218 Left side/ die Linke
360
x 1
58 x 224 x 2218
362
x 1
44 x 751 x 2300
364
x 1
3 x 150 x 835
559
x 1
Plexiglas
40 x 60 x 989
x 5 860
40 x 60 x 1878
867
x 1
41 x 41 x 2000
x 2 1094
41 x 41 x 1000
1083
x 8
1085
x 4 19 x 90 x 1235
1087
x 2 19 x 90 x 1860
Pcs.
x 6
x 1
x 1
x 1
x 1
x 2
x 1
x 1
x 1
x 10
x 8
x 2
2
