• Prevent torsion loads. Do not pull on the con-
nected hose.
• Symbols affixed to your tools may not be
removed or covered. Information on the device
that is no longer legible must be replaced imme-
diately.
Before putting the unit into operation, read
and observe the instructions for use.

Scope of delivery

► Scope of delivery – p. 3
1. Controller
2. Suction hose with filter
3. Barb tee (10×)
4. Dripper (10×)
5. End plug (2×)
6. Tube holder stake (10×)
7. USB charging line
8. Bottle adaptor
9. Hanger
10. Irrigation pipe
11. Vent valve

Assembly and installation

► P. 4, item 1
– Assemble the watering system as shown in the
illustration. Cut the tube (10) into the desired
lengths. Use T-pieces (3), plugs (5) and drip
heads (4) to assemble the watering system in the
desired configuration and connect it to the con-
troller's side connection. It is easier to put on the
tube if the ends of the tube are held in hot water
beforehand.
► P. 4, item 2
The system can use different water sources:
A. A small plastic bottle can be attached from above
the controller without a bottle adapter. This is
ideal for watering miniplants that require little
water.
B. In larger bottles, e.g. 4l, 5l, 6l, the pump control
system must be connected with the thread of the
bottle cover; use the bottle adaptor (8).
C. Any open container, e.g. a bucket, can be used.
To hang the controller on the container, use the
bracket (9).
• The suction hose (2) is then hung as deep as
possible in the water container.
► P. 5, item 3
• If the flower pots are located above the water
level, it is not necessary to connect the vent
valve.
► P. 5, item 4
• If the flower pots are located below the water
level, you must connect the vent valve.

Controller programming

– Set the desired span between waterings with
the [ ] knob.
– Set the watering time with the [
duration of watering cannot be greater than the
value of the frequency of watering!
– Set the start time for watering by delaying the first
– If the watering, in case of this example, is sup-
– Assemble the watering system as shown in the
Example:
• You need to water every day for 5 minutes. Set -
• The next watering time will be recalculated if you
Notes:
• The water flow rate of the product is significantly
• The maximum water flow rate is distributed
• The amount of water per dropper can be adjusted
• LED will blink every 4 seconds, if it flashes
Power button [
• If press longer than 5 seconds, it can be used as

Extend the Duration of the Battery

You can use extra energy from a powerbank to
extend the duration of the system. Make same dura-
tion tests before leaving plants alone during your hol-
idays, to make sure of a good result. Total duration
will depend of the kind of powerbank used.
Important: Please make sure powerbank is safe from
water. Do not use it outdoors. Humidity on the enviro-
ment and sun could spoil it. At the same time spoiled
powerbank can spoil the unit too.

More Important Precautions

• Prolong the life of the product you have just
• Never put the timer to be charged to the wall by
] knob. The
watering from the current time. To do this, press
the [ ] button for more than 2 seconds until the
LED is constantly on. Each subsequent press of
the button adds one hour to delay the start of
watering. For example: if the time is now 12:00,
and you need to start watering at 18:00, you need
to postpone watering for 6 hours. To do this,
press the [ ] button six times.
posed to start at 5 PM, then you should press
the [ ] button 5 times.
illustration. Cut the tube (10) into the desired
lengths. Use T-pieces (3), plugs (5) and drip
heads (4) to assemble the watering system in the
desired configuration and connect it to the con-
troller's side connection. It is easier to put on the
tube if the ends of the tube are held in hot water
beforehand.
[ ] = 24 hours; [ ] = 5 minutes.
change the frequency or duration of watering.
dependent on the height to be overcome and the
number of droppers used.
almost uniformly across the number of droppers
used.
using the adjusting screw of the droppers.
quickly, like 1 blink each second, it means low
battery, the battery can be recharged with USB
charging cable. In low battery, controller is shut
off.
] or manual watering:
a Power ON/OFF button. If press for 1 second, it
is for manual watering. Manual watering will be
automatically turned off after 15 minutes.
bought, leaving it protected from the sun and
rain. Do not use it with temperatures below 0 °C
or above 45 °C.
the USB connection while the system is in use
with water. Remove the unit from any water
source and dry it before charging it.
