2.2 Mounting your Handsfree

The HCC-250 Car-Kit can be easily mounted inside the car by either using the companion Sun-Visor Clip to fix the product on the sun-visor over the driver's seat,
or inserting the Vent Mount Clip into the vent in front of the driver's seat.
As shown in Figures 3 and 4, there are two magnetic tips on the backside of the device. You can attach the Sun-Visor Clip or the Vent Mounting Clip to them.
For better mounting the device, please clip the Sun-Visor Clip to the sun visor first, and then properly attach the Car-Kit to the Sun-Visor Clip.
To use the Vent Mounting Clip, you may adjust the clip direction according to your car vent, as shown in Figure 5.
Note: The microphone of the HCC-250 Car-Kit must aim at the sound bearing.
Figure 3: Attach Sun-visor Clip to Magnetic Tips
With great portability and flexibility, this Car-Kit can also be used outside of such car environment such as in office and/or at home.
2.3 Turn On/Off the HCC-250 Car-Kit
Turn on the Handsfree: Press and hold button
3 seconds; the Red LED is off. This indicates the handsfree is power on.
Turn off the HCC-250: Press and hold button
This indicates the Car-Kit is power off.
Magnetic Tip
Sun-Visor Clip
Vent Mounting Clip
(Vertical Direction)
Metal Base
Figure 5: Adjust Vent Mounting Clip Direction (Vertical or Horizontal)
Figure 6: Detach Clip from metal base
for at least 3 seconds, you will hear 2 power-up tones, the Blue LED gives 3 quick blinks following by 1 blink per
for at least 3 seconds, you will hear 2 power-down tones, the Red LED will blink 3 times then all LEDs are off.
HCC-250 - English
Page 4
Figure 4: Attach Vent Mount Clip to Magnetic Tips
Vent Mounting Clip
(Horizontal Direction)
Pull out a little and push
down from here
Vent Mount Clip
