• Using the tool for different applications, or with
different or poorly maintained accessories, may
signifi cantly increase the exposure level.
• The times when the tool is switched off or when
it is running but not actually doing the job, may
signifi cantly reduce the exposure level.
Protect yourself against the effects of vibration by
maintaining the tool and its accessories, keeping
your hands warm, and organizing your work patterns.
DESCRIPTION
The numbers in the text refer to the diagrams on
page 2.
1. Machine
2. Battery
3. Battery unlock button
4. Work light
5. On / off switch
6. Torque adjustment ring
7. Chuck
8. Gear selection switch
9. Direction switch
10. Belt hook
11. Operation mode ring
12. Battery LED indicators button
13. Battery LED indicators
14. Charger
15. Charger LED indicators
3. ASSEMBLY
Before any work on the power tool, remove
the battery.
The battery must be charged before fi rst use.
Inserting the battery into the machine (Fig. B)
Ensure that the exterior of the battery is
clean and dry before connecting to the
charger or machine.
1. Insert the battery (2) into the base of the machine
as shown in Fig. B.
2. Push the battery further forward until it clicks
into place.
Removing the battery from the machine (Fig. B)
1. Push the battery unlock button (3).
WWW.VONROC.COM
2. Pull the battery out of the machine like shown
in Fig. B.
Checking the battery charging status (Fig. C)
• To check the battery charge status, push the
button (12) on battery shortly.
• The battery has 3 lights indicating the charge
level, the more lights that burn, the more charge
the battery has left.
• When the lights are not burning it means the bat-
tery is empty and must be charged immediately.
Charging the battery with the charger (Fig. C)
1. Take the battery (2) from the machine.
2. Turn the battery (2) to upside down position and
slide it onto the charger (14) as shown in Fig. C.
3. Push the battery until it is fully pushed into the
slot.
4. Plug the charger plug into an electrical outlet and
wait for a while. The LED indicators on the charger
(15) will lighten up and show the charger status.
The charger has 2 LED indicators (15) which indi-
cate the status of the charging process:
Red LED Status Green LED status
Off Off
Off On
On Off
• Fully charging the 2Ah battery may take up to
60 minutes.
• Fully charging the 4Ah battery may take up to
120 minutes.
After the battery is fully charged remove the char-
ger plug from the outlet and remove the battery
from the charger.
When the machine is not being used over a
longer period of time it is best to store the
battery in charged condition.
EN
Charger status
No power
Standby mode:
- No battery is
inserted or,
- Battery
inserted but
charging has
fi nished
Battery charging in
progress
7
