SE Rupert Neve Designs RNR1 Bedienungsanleitung Seite 9

Technical Specifications (RN17)
Capsule Type
Diaphragm
Polar pattern
Frequency range
Sensitivity
Max. SPL (0.5% THD @1kHz)
Signal to noise ratio
Self noise
Power requirements
Electrical Impedance
Matching Connectors
Diameter
Length
Weight
Stereo Bar (Matched Stereo Pair Only)
Weight
Dimensions
Max. width between mic mounts
Min. width between mic mounts
Frequency response
Hand-Crafted True Condenser
17.2mm Gold/Mylar
Cardioid (omnidirectional capsule available separately)
20 Hz – 20 kHz
5.96 mV/Pa (-44.5dB)
131 dB
76 dB
18 dB(A) cardioid, 15 dB(A) omni
+48V phantom power
200 Ohms
XLR3F
44 mm (transformer), 17 mm (capsule)
200 mm
320 g / 11.32 oz
245 g / 8.64 oz
300 x 25 mm
276 mm
58 mm
Polar Pattern
9
