Frequency Response; Polar Pattern - SE Rupert Neve Designs RNR1 Bedienungsanleitung

Technical Specifications (RNR1)
Acoustic operating principle
Transducer

Polar pattern

Frequency range
Sensitivity
Max. SPL (0.5% THD @1kHz)
Signal to noise ratio
Self noise
Low cut filter switch
Power requirements
Electrical Impedance
Matching Connectors
Dimensions
Weight

Frequency response

Figure-8
Electrodynamic pressure gradient with active electronics
Hand-tensioned 2.5µm aluminum ribbon
Figure-8
20 Hz – 20 kHz
25 mV/Pa (-32 dB)
137 dB
SPL
77 dB
17 dB(A)
100 Hz
+48V phantom power
200 Ohms
XLR3F
47mm (diameter) x 268mm (height)
860g / 30.34oz
Polar Pattern
8
