Instructions for Use – EASyS Modular S seat unit
Foot straps (Fig. 51)
Both foot straps position the user's feet directly on the foot plate of the footrest. The feet are no longer able to slip.
Calf strap (Fig. 52)
The calf strap is affixed between the two lateral posts of the footrest and supports the user's lower legs.
Footrest post padding (Fig. 53)
The padding for the footrest protects the user's lower leg.
Sleeping bag, padded / woven fur (Fig. 54)
The sleeping bag extends from the seat to the footrest. The padded model protects the user in cool weather. The woven
fur model protects the user in cold weather.
Rain cover, transparent, with leg blanket (Fig. 55)
The clear rain cover with leg blanket protects the user and the product in wind and rain. The user has a clear view of
the surroundings.
Sun / rain cover (Fig. 56)
The sun / rain cover fully protects the user from direct sun rays, glare, wind, and overstimulation from sights and sounds
in the environment. The caregiver can, if needed, watch the user through a flap.
Sun / rain cover with leg blanket (Fig. 57)
The sun / rain cover fully protects the user fully from direct sun rays, glare, wind, and overstimulation from sights and
sounds in the environment. The caregiver can, if needed, watch the user through a flap. The leg blanket also protects
the user's legs and feet.
Rain shield (Fig. 58)
The transparent rain shield fully protects the user and the product in wet and rainy conditions. The rain shield is a trans-
parent tarp that can only be used in combination with a sun and rain cover.
Umbrella (Fig. 59)
The umbrella is affixed to the left or right of the rolling chassis. It protects the user from direct sun rays and glare.

Technical Data

EASyS Modular S seat unit
Seat depth
Seat width
Back height
Lower leg length
Back angle
Knee angle
Foot angle
Turning range of seat
Seat tilt-in-space (on A-Chassis Advantage), driving direction -10° to +35°
Seat tilt-in-space (on A-Chassis Advantage), face-to-face
Size of hip guide (w x h)
Size of footrest (w x d)
Overall dimensions
(on A-Chassis Advantage) (l x w x h)
Folded dimensions
(on A-Chassis Advantage) (l x w x h)
Weight (seat)
Max. user weight (seat)
28
Size 1
190 - 300 mm / 7.5 - 11.8"
190 - 260 mm / 7.5 - 10.2"
280 - 420 mm / 11.0 - 16.5"
185 - 305 mm / 7.3 - 12.0"
90° to 140°
90° to 180°
78° to 100°
180°
0° to +35°
230 x 120 mm / 9.1 x 4.7"
280 x 180 mm / 11 x 7.1"
995 x 595 x 1140 mm
39.2 x 23.4 x 44.9"
850 x 595 x 600 mm
33.5 x 23.4 x 23.6"
8,8 kg / 19.8 lbs
35 kg / 77.2 lbs
Size 2
270 - 380 mm / 10.6 - 15"
270 - 350 mm / 10.6 - 13.8"
340 - 530 mm / 13.4 - 20.9"
185 - 370 mm / 7.3 - 14.6"
90° to 140°
90° to 180°
78° to 100°
180°
-10° to +35°
0° to +35°
290 x 110 mm / 11.4 x 4.3"
320 x 210 mm / 12.6 x 8.3"
1070 x 690 x 1200 mm
42.1 x 27.2 x 47.2"
810 x 690 x 690 mm
31.9 x 27.2 x 27.2"
11 kg / 24.3 lbs
40 kg / 88.2 lbs
2021-04
