E-SMART

Use and maintenance

Lubrication
Insert the tip of the grease gun in the specific grease blocks
(Fig.1). Repeat this operation every 2000 km or 1 year of use
based on the value reached first.
Type of lubricant: Lithium soap grease of class No. 2.

Preliminary operations

1) Take the measurement of the distance X between the
carriage and the belt tensioner (Fig.2)
UM-2
For specially stressed applications or difficult environemen-
tal conditions, lubrication should be carried out more fre-
quently. Apply to Rollon for further advice
Quantity of lubricant for each block:
Fig. 1
2) Remove the belt tensioner untightening both the vertical
X
Fig. 2
Fig. 3
Type
E-SMART 30
E-SMART 50
E-SMART 80
E-SMART 100
and horizontal screws on the carriage (Fig.3 - Fig.4 - Fig.5)
Quantity
[cm ]
3
0.5
0.2
0.5
0.6
Tab. 1
Fig. 4
Fig. 5
