Table of Motherboard Components
LABEL
1. CPU Socket
2. CPU_FAN
3. DIMM1~2
4. BZ
5. ATX_POWER
6. F_USB3.0
7. SATA1~5
8. F_PANEL
9. CLR_CMOS
10. ME_DIS
11. F_USB1~2
12. TPM
13. LPT
14. COM2
15. F_AUDIO
16. PCI
17. CASE
18. PCIEX1_1~2
19. BAT1
20. PCIE16X
21. M.2
22. SYS_FAN
23. ATX_12V
Please take the actual motherboard as standard.
*1 Only B150M4-C43 has five SATA connectors, H110M4-C43 has three SATA
connectors, and H110M4-C33 has four SATA connectors.
*2 H110M4-C33 does not have M.2 slot.
H110M4-C43(C33)/B150M4-C43 USER MANUAL
4
COMPONENTS
LGA1151 socket for Intel
4-pin CPU cooling fan connector
288-pin DDR4 Module slots
Buzzer header
Standard 24-pin ATX power connector
Front panel USB 3.0 header
Serial ATA 6Gb/s connectors*
Front panel switch/LED header
Clear CMOS jumper
ME disable header
Front panel USB 2.0 headers
Trusted platform module header
Onboard parallel port header
Onboard serial port header
Front panel audio header
32-bit PCI add-on card slot
CASE open header
PCI Express Gen2 x1 slots
Battery
PCI Express x16 slot Gen3 for graphics interface
M.2 slot for 2280 SSD card (SATA
4-pin system cooling fan connector
4-pin +12V power connector
®
Skylake processor
1
2
only)*
