Brief Introduction

Specifications

CPU
•
•
Note: Please go to ECS website for the latest CPU support list.
Chipset •
Memory •
•
•
Note: Please go to ECS website for the latest Memory support list.
Expansion
•
Slots
•
•
•
Storage •
•
Audio
LAN •
•
Rear Panel I/O
•
•
•
•
•
•
•
•
Internal I/O •
Connectors & •
Headers •
•
•
•
•
•
•
•
•
•
•
•
•
•
H110M4-C43(C33)/B150M4-C43 USER MANUAL
LGA1151 socket for Intel
Supports CPU up to 95W
®
Intel H110/B150 Chipset
Dual-channel DDR4 memory architecture
2 x 288-pin DDR4 LONG DIMM sockets support up to 32 GB
Supports DDR4 2133 MHz DDR4 SDRAM
1 x PCI Express x16 Gen3 slot
2 x PCI Express x1 Gen2 slots
1 x PCI slot
1 x M.2 slot for 2280 SSD card (SATA
®
Supported by Intel H110/B150 Express Chipset
- 5 x Serial ATA 6Gb/s
Realtek ALC662-VD0-GR 6-CH High Definition audio CODEC
- Compliant with HD audio specification
Realtek RTL8111GN Gigabit Lan
1 x PS/2 mouse & PS/2 keyboard connector
1 x Serial port (COM1 port)
1 x HDMI port
1 x D-sub port (VGA port)
1 x DVI-D port
2 x USB 3.0 ports
1 x RJ45 LAN connector
2 x USB 2.0 ports
1 x Audio 6-ch jacks (line-in, line-out, microphone)
1 x 24-pin ATX Power Supply connector
1 x 4-pin ATX 12V Power connector
1 x 4-pin CPU_FAN connector
1 x 4-pin SYS_FAN connector
1 x USB 3.0 header supports additional two USB 3.0 ports
2 x USB 2.0 headers support additional four USB 2.0 ports
5 x SATA 6Gb/s connectors*
1 x Front Panel audio header
1 x Front Panel switch/LED header
1 x Onboard parallel port header
1 x COM header (COM2)
1 x Clear CMOS jumper
1 x Trusted platform module header (TPM)
1 x Buzzer header
1 x Case open header
1 x ME disable header
®
Skylake processor
1
only)*
2
devices*
2
1
