Tool Specifications

Cordless screwdriver
Article number
Rated voltage
No-load speed
1st gear
2nd gear
Torque adjustment range
Max. torque for hard/soft screwdriving
application according to ISO 5393
Maximum drilling Ø (1st/2nd gear)
Steel
Wood
Screw diameter, max.
Chuck clamping range
Drill spindle thread
Weight according to EPTA-Procedure 01 /2003
Please observe the article number on the type plate of your machine. The trade names of the individual machines may vary.

Machine Elements

The numbering of the machine elements refers to
the illustration of the machine on the graphics
page.
1 Gear selector
2 Torque setting ring
3 Keyless chuck
4 On/Off switch
5 Rotational direction switch
6 Screwdriver blade*
7 Battery*
8 Battery unlocking button
9 Soft grip
10 Screwdriver bit*
11 Universal bit holder*
12 Locking screw
13 Allen key*
* Not all of the accessories illustrated or described are
included as standard delivery.

Noise/Vibration Information

Measured values determined according to
EN 60 745.
Typically the A-weighted sound pressure level of
the machine is less than 70 dB (A).
The noise level when working can exceed
85 dB (A).
Wear hearing protection!
The typical hand/arm vibration is below 2.5 m/s
8 • 2 609 932 475 • TMS • 06.06.05
PSR 12
3 603 J53 5..
[V=] 12
[rpm] 0 – 390
[rpm] 0 – 1 250
[Nm] 0.7 – 9.0
[Nm] 24/12
[mm] 10/10
[mm] 20/19
[mm] 6
[mm] 1 – 10
3/8"
[kg] 1.6

For Your Safety

Read all instructions. Failure to fol-
low all instructions listed below may
result in electric shock, fire and/or se-
rious injury.
Additionally, the general safety instructions either
in the enclosed booklet or those added in the
centre of these operating instructions must be ob-
served.
SAVE THESE INSTRUCTIONS.
Secure the workpiece. A workpiece clamped
with clamping devices or in a vice is held more
securely than by hand.
Do not work materials containing asbes-
tos. Asbestos is considered carcinogenic.
Take protective measures when dust can
develop during working that is harmful to
one's health, combustible or explosive. Ex-
ample: Some dusts are regarded as carcino-
genic. Wear a dust mask and work with dust/
chip extraction when connectable.
Keep your workplace clean. Material mix-
tures are particularly dangerous. Dust of light
metal can be inflammable or explode.
Always wait until the machine has come to
a complete stop before placing it down. The
tool insert can jam and lead to loss of control
over the power tool.
2
.
English - 1
PSR 14,4
3 603 J53 4..
14.4
0 – 400
0 – 1 250
0.7 – 9.0
30/16
10/10
28/20
7
1 – 10
3/8"
1.8
